3-27
DVD loading switch board
(FMU-DE3-21M) (TH-S7,TH-S9)
Block No. [0][7][0][0]
DVD servo board
(FTU-DE3-2M) (TH-S8)
Block No. [0][8][0][0]
R733 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R734 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R735 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R741 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R742 NRSA63J-5R1X MG RESISTOR 5.1 Ω 1/16W J
R743 NRSA63J-4R7X MG RESISTOR 4.7
Ω 1/16W J
R744 NRSA63J-4R7X MG RESISTOR 4.7
Ω 1/16W J
R745 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R749 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R792 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R990 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
CN101 QGF0523F1-24W CONNECTOR FFC/FPC (1-24)
CN201 QGF1037F1-08W CONNECTOR FFC/FPC (1-8)
CN501 QGF1016F2-08W CONNECTOR FFC/FPC (1-8)
CN502 QGF1016F2-09W CONNECTOR FFC/FPC (1-9)
CN503 QGF1016F2-17W CONNECTOR FFC/FPC (1-17)
CN504 QGF1016F2-15W CONNECTOR FFC/FPC (1-15)
CN511 QGF0523F1-16W CONNECTOR FFC/FPC (1-16)
K101 NRSA02J-0R0X MG RESISTOR 0 Ω 1/10W J
K102 NRSA02J-0R0X MG RESISTOR 0
Ω 1/10W J
K350 NQR0502-001X FERRITE BEADS
K352 NQR0502-001X FERRITE BEADS
K551 NQR0129-002X FERRITE BEADS
K552 NQR0129-002X FERRITE BEADS
K553 NQR0129-002X FERRITE BEADS
K554 NQR0129-002X FERRITE BEADS
K555 NQR0022-005X FERRITE BEADS
K556 NQR0129-002X FERRITE BEADS
K591 NQR0022-005X FERRITE BEADS
K592 NQR0022-005X FERRITE BEADS
K593 NQR0022-005X FERRITE BEADS
K594 NQR0022-005X FERRITE BEADS
K595 NQR0022-005X FERRITE BEADS
K596 NQR0022-005X FERRITE BEADS
K597 NQR0022-005X FERRITE BEADS
K598 NQR0022-005X FERRITE BEADS
K599 NQR0022-005X FERRITE BEADS
K710 NQR0129-002X FERRITE BEADS
K791 NQR0502-001X FERRITE BEADS
TH301 NAD0025-103X N THERMISTOR 10k
Ω
X351 NAX0550-001X CRYSTAL 27.000MHz
 Symbol No. Part No. Part Name Description Local
CN1 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1007-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0004AA-H IC
IC302 LM1117MP-ADJ-X IC
IC305 MM1563DF-X IC 3.3V Regulator
IC453 S-80830CNNB-G-W IC
IC505 K4S643232F-TC60 IC
IC505 or K4S643232H-TC60 IC
IC509 AT49BV322AT70TI IC(FLASH)
IC509 or MBD32TF70TN IC(MICRO C ROM)
IC512 SN74LVC373APW-X IC(DIGITAL)
 Symbol No. Part No. Part Name Description Local
IC513 SN74LVC373APW-X IC(DIGITAL)
IC701 AK4384VT-X IC
IC702 AK4384VT-X IC
IC703 AK4384VT-X IC
IC704 CS5342-CZZ-X IC(DIGITAL)
IC705 MM1615AN-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 UN2119-X TRANSISTOR
C101 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C108 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C261 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C262 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C300 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C301 NEA70GM-227X E CAPACITOR 220uF 4V M
C302 NEA70GM-476X E CAPACITOR 47uF 4V M
C303 NEA70GM-476X E CAPACITOR 47uF 4V M
C304 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C305 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C306 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C307 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C308 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C309 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C310 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C311 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C312 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C313 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C314 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C315 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C316 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C317 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C318 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C319 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C320 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C321 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C322 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C323 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C324 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C325 NDC31HJ-180X C CAPACITOR 18pF 50V J
C326 NDC31HJ-150X C CAPACITOR 15pF 50V J
C328 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C329 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C330 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C331 NCB31CK-333X C CAPACITOR 0.033uF 16V K
C332 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C333 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C334 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C335 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C337 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C338 NCB31HK-562X C CAPACITOR 5600pF 50V K
C339 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C340 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C341 NCF31AZ-105X C CAPACITOR 1uF 10V Z
C347 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C348 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
