JVC TH-SW9

3-18
TX ant board
Block No. [0][4]
Front board (Receiver)
Block No. [0][5]
R1158 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1161 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1162 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1163 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1164 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R1165 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1166 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R1167 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1168 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J
R1169 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R1170 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R1171 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J SW8
R1171 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J SW9
R1172 NRSA63J-332X MG RESISTOR 3.3k Ω 1/16W J SW8
R1172 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J SW9
R1173 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1174 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R1175 NRSA63J-432X MG RESISTOR 4.3k Ω 1/16W J
R1176 NRSA63J-393X MG RESISTOR 39k Ω 1/16W J
R1180 NRSA63J-222X MG RESISTOR 2.2k Ω 1/16W J
R1181 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R1182 NRSA63J-202X MG RESISTOR 2k
Ω 1/16W J SW8
R1182 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J SW9
R1183 NRSA63J-202X MG RESISTOR 2k Ω 1/16W J SW8
R1183 NRSA63J-392X MG RESISTOR 3.9k Ω 1/16W J SW9
R1197 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R1201 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R1202 NRSA63J-124X MG RESISTOR 120k Ω 1/16W J
R1251 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R1252 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R1253 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R1254 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R2525 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2526 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2531 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2532 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2533 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2534 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2537 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2538 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2539 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R2540 NRSA63J-272X MG RESISTOR 2.7k Ω 1/16W J
R2551 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2552 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2553 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2554 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2560 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R2561 NRSA63J-273X MG RESISTOR 27k Ω 1/16W J
R2562 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2563 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2564 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R2565 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R2566 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R2567 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2568 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2581 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R2582 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R2583 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R2584 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2585 NRSA63J-682X MG RESISTOR 6.8k
Ω 1/16W J
R2586 NRSA63J-123X MG RESISTOR 12k
Ω 1/16W J
R2587 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R2588 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2590 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R2592 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R2594 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R2596 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R2599 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6001 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R6002 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R6003 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R6004 NRSA63J-101X MG RESISTOR 100
Ω 1/16W J
R6006 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
CN441 QGF1036C1-29 CONNECTOR FFC/FPC (1-29)
CN442 QGF1036C1-07 CONNECTOR FFC/FPC (1-7)
CN443 QGA2501C1-03 CONNECTOR W-B (1-3)
CN511 QGF1036F1-13 CONNECTOR FFC/FPC (1-13)
 Symbol No. Part No. Part Name Description Local
EP101 E409182-001SM GRAND TERMINAL
J1101 QNN0215-001 SURROUND JACK
J1103 QND0118-001 DIN CONNECTOR
J6001 QNS0231-001 JACK
JS541 QSW1059-001 JOG VOLUME
K1101 NQR0007-002X FERRITE BEADS
K6001 NQR0007-002X FERRITE BEADS
K6002 NQR0007-002X FERRITE BEADS
K6003 NQR0007-002X FERRITE BEADS
K6004 NQR0007-002X FERRITE BEADS
S521 QSW0683-001Z PUSH SW
S522 QSW0683-001Z PUSH SW
S523 QSW0683-001Z PUSH SW
S526 QSW0683-001Z PUSH SW
S527 QSW0683-001Z PUSH SW
S528 QSW0683-001Z PUSH SW
W6001 QUB220-15DMHP SINGLE WIRE
 Symbol No. Part No. Part Name Description Local
TP701 QNZ0104-001 POST PIN
 Symbol No. Part No. Part Name Description Local
IC101 TDA8920TH/N1-X IC
IC131 RC4580ID-X IC
Q1501 KTC3875/YG/-X SI TRANSISTOR
Q1502 UN2213-X DIGI TRANSISTOR
Q1503 KTC3875/YG/-X SI TRANSISTOR
Q1504 UN2214-X TRANSISTOR
Q1505 KTC3875/YG/-X SI TRANSISTOR
Q1601 KTA1504/YG/-X SI TRANSISTOR
Q1602 KTC3875/YG/-X SI TRANSISTOR
Q1603 KTC3875/YG/-X SI TRANSISTOR
Q1604 UN2112-X DIGI TRANSISTOR
Q1620 2SA1514K/RS/-X TRANSISTOR
Q1621 2SA1514K/RS/-X TRANSISTOR
Q1630 2SA1514K/RS/-X TRANSISTOR
Q1631 2SA1514K/RS/-X TRANSISTOR
D1501 MA111-X SI DIODE
D1502 MA111-X SI DIODE
D1503 MA111-X SI DIODE
D1504 MA111-X SI DIODE
D1505 MA111-X SI DIODE
D1507 MA111-X SI DIODE
D1508 MA111-X SI DIODE
D1601 MA111-X SI DIODE
D1620 MA111-X SI DIODE
D1621 MA111-X SI DIODE
D1630 MA111-X SI DIODE
D1631 MA111-X SI DIODE
D1640 MA111-X SI DIODE
D1711 MTZJ13C-T2 Z DIODE
D1801 SELU2E10C-P LED
D1802 SLR-343VC-T LED
C1001 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1002 NCF21HZ-474X C CAPACITOR 0.47uF 50V Z
C1003 NCB21HK-104X C CAPACITOR 0.1uF 50V K
C1004 NCB31HK-331X C CAPACITOR 330pF 50V K
C1005 NCF21HZ-474X C CAPACITOR 0.47uF 50V Z
C1006 NCB31HK-331X C CAPACITOR 330pF 50V K
 Symbol No. Part No. Part Name Description Local
