JVC TH-SW9

3-20
Mother board
Block No. [0][6]
K1702 NQR0353-003X FERRITE BEADS
K1703 NQR0353-003X FERRITE BEADS
K1704 NQR0353-003X FERRITE BEADS
RY161 QSK0109-001 RELAY
 Symbol No. Part No. Part Name Description Local
 IC201 STK413-430 IC
 IC202 STK413-400 IC
IC301 RC4558D-X IC
IC302 RC4558D-X IC
IC303 RC4558D-X IC
IC601 MN101C427NB IC
IC602 S-80840CNNB-W IC
Q151 KTC2026/Y/ TRANSISTOR
Q152 KTC3203/OY/-T TRANSISTOR
Q501 UN2113-X DIGI TRANSISTOR
Q502 UN2211-X TRANSISTOR
Q503 KTC3875/YG/-X SI TRANSISTOR
Q504 KTA1504/YG/-X SI TRANSISTOR
Q505 UN2211-X TRANSISTOR
Q517 UN2213-X DIGI TRANSISTOR
Q523 KTC3875/YG/-X SI TRANSISTOR
Q524 KTA1504/YG/-X SI TRANSISTOR
Q525 KTC3875/YG/-X SI TRANSISTOR
Q542 KTC3875/YG/-X SI TRANSISTOR
Q603 KTC3875/YG/-X SI TRANSISTOR
Q604 KTC3265/Y/-X TRANSISTOR
Q2101 KTA1504/YG/-X SI TRANSISTOR
Q2201 KTA1504/YG/-X SI TRANSISTOR
Q2301 KTA1504/YG/-X SI TRANSISTOR
Q2401 KTA1504/YG/-X SI TRANSISTOR
Q2501 KTA1504/YG/-X SI TRANSISTOR
Q2601 KTA1504/YG/-X SI TRANSISTOR
Q2701 KTC3875/YG/-X SI TRANSISTOR
Q2702 KTA1046/Y/ TRANSISTOR
Q2703 UN2211-X TRANSISTOR
Q3101 KTC3875/YG/-X SI TRANSISTOR
Q3102 KTC3875/YG/-X SI TRANSISTOR
Q3201 KTC3875/YG/-X SI TRANSISTOR
Q3202 KTC3875/YG/-X SI TRANSISTOR
Q3301 KTC3875/YG/-X SI TRANSISTOR
Q3302 KTC3875/YG/-X SI TRANSISTOR
Q3401 KTC3875/YG/-X SI TRANSISTOR
Q3402 KTC3875/YG/-X SI TRANSISTOR
Q3501 KTC3875/YG/-X SI TRANSISTOR
Q3502 KTC3875/YG/-X SI TRANSISTOR
Q3701 UN2111-X TRANSISTOR
Q3702 UN2111-X TRANSISTOR
Q3703 UN2212-X DIGI TRANSISTOR
Q3704 KTC2026/Y/ TRANSISTOR
Q3705 KTC3875/YG/-X SI TRANSISTOR
Q3706 UN2213-X DIGI TRANSISTOR
D101 1SS133-T2 DIODE
 D151 GBU803 BRIDGE DIODE
 D152 GBU803 BRIDGE DIODE
D153 1SS133-T2 DIODE
D154 1SS133-T2 DIODE
D161 1SS133-T2 DIODE
D162 MTZJ13C-T2 Z DIODE
D163 1SS133-T2 DIODE
D164 MTZJ6.2A-T2 Z DIODE
D165 MTZJ6.8C-T2 Z DIODE
D166 MTZJ6.8C-T2 Z DIODE
D501 1SS133-T2 DIODE
D502 1SS133-T2 DIODE
D503 1SS133-T2 DIODE
D504 1SS133-T2 DIODE
D505 MTZJ5.1C-T2 Z DIODE
 Symbol No. Part No. Part Name Description Local
D506 1SS133-T2 DIODE
D507 1SS133-T2 DIODE
D509 1SS133-T2 DIODE
D510 1SS133-T2 DIODE
D514 1SS133-T2 DIODE
D518 MTZJ15C-T2 Z DIODE
D519 1SS133-T2 DIODE
D520 1SS133-T2 DIODE
D521 MTZJ6.8C-T2 Z DIODE
D535 1SS133-T2 DIODE
D541 1SS133-T2 DIODE
D542 1SS133-T2 DIODE
D543 1SS133-T2 DIODE
D544 1SS133-T2 DIODE
D545 1SS133-T2 DIODE
D546 1SS133-T2 DIODE
D548 1SS133-T2 DIODE
D549 1SS133-T2 DIODE
D550 1SS133-T2 DIODE
D551 1SS133-T2 DIODE
D552 1SS133-T2 DIODE
D553 1SS133-T2 DIODE
D561 SLR-342MC-T12 LED
D601 1SS133-T2 DIODE
D610 1SS133-T2 DIODE
D611 1SS133-T2 DIODE
D2101 1SS133-T2 DIODE
D2201 1SS133-T2 DIODE
D2301 1SS133-T2 DIODE
D2401 1SS133-T2 DIODE
D2501 1SS133-T2 DIODE
D2601 1SS133-T2 DIODE
D2701 MTZJ13C-T2 Z DIODE
D2702 MTZJ13C-T2 Z DIODE
D2703 MTZJ16C-T2 Z DIODE
D3101 1SS133-T2 DIODE
D3102 1SS133-T2 DIODE
D3201 1SS133-T2 DIODE
D3202 1SS133-T2 DIODE
D3301 1SS133-T2 DIODE
D3302 1SS133-T2 DIODE
D3401 1SS133-T2 DIODE
D3402 1SS133-T2 DIODE
D3501 1SS133-T2 DIODE
D3502 1SS133-T2 DIODE
D3601 1SS133-T2 DIODE
D3602 1SS133-T2 DIODE
D3703 MTZJ11C-T2 Z DIODE
D3706 1SS133-T2 DIODE
D3707 1SS133-T2 DIODE
D3708 1SS133-T2 DIODE
 C101 QCZ9105-472 C CAPACITOR 4700pF 250V M
C151 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C152 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C153 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C154 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C155 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C156 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C157 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C158 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C159 NCF21HZ-104X C CAPACITOR 0.1uF 50V Z
C161 QETM1HM-338 E CAPACITOR 3300uF 50V M
C162 QETM1HM-338 E CAPACITOR 3300uF 50V M
C163 QETM1EM-478 E CAPACITOR 4700uF 25V M
C164 QETM1EM-478 E CAPACITOR 4700uF 25V M
C165 QETN1EM-476Z E CAPACITOR 47uF 25V M
C166 QETN1EM-107Z E CAPACITOR 100uF 25V M
C167 QETN1EM-476Z E CAPACITOR 47uF 25V M
C168 QETN1CM-107Z E CAPACITOR 100uF 16V M
C171 QETN1CM-107Z E CAPACITOR 100uF 16V M
C172 QETN1CM-107Z E CAPACITOR 100uF 16V M
C501 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C502 NCF31HZ-103X C CAPACITOR 0.01uF 50V Z
C503 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C512 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C522 QETN1HM-106Z E CAPACITOR 10uF 50V M
C523 QETN1EM-476Z E CAPACITOR 47uF 25V M
 Symbol No. Part No. Part Name Description Local
