JVC TH-SW9

3-23
DVD servo board
Block No. [0][7]
R3404 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3405 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3406 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3407 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3408 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3409 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R3410 NRSA63J-104X MG RESISTOR 100k
Ω 1/16W J
R3411 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3412 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3413 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3501 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3502 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R3503 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R3504 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3505 NRSA63J-474X MG RESISTOR 470k Ω 1/16W J
R3506 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3507 NRSA63J-334X MG RESISTOR 330k Ω 1/16W J
R3508 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3509 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R3510 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3511 NRSA63J-471X MG RESISTOR 470
Ω 1/16W J
R3512 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R3513 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3601 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3602 NRSA63J-183X MG RESISTOR 18k Ω 1/16W J
R3603 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R3604 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3605 NRSA63J-154X MG RESISTOR 150k Ω 1/16W J
R3607 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3608 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3610 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3611 NRSA63J-471X MG RESISTOR 470 Ω 1/16W J
R3717 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R3718 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R3719 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
 R3720 QRJ146J-100X UNF C RESISTOR 10 Ω 1/4W J
R3721 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R3725 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R3726 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
 R3727 QRL01DJ-180X OMF RESISTOR 18 Ω 1W J
R3728 NRSA63J-101X MG RESISTOR 100 Ω 1/16W J
R3729 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R3730 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R3732 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R3741 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R3742 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
L2101 QQLZ038-R45 COIL 0.45uH
L2201 QQLZ038-R45 COIL 0.45uH
L2202 QQLZ038-R45 COIL 0.45uH
L2301 QQLZ038-R45 COIL 0.45uH
L2302 QQLZ038-R45 COIL 0.45uH
L2401 QQLZ038-R45 COIL 0.45uH
L2402 QQLZ038-R45 COIL 0.45uH
L2501 QQLZ038-R45 COIL 0.45uH
L2502 QQLZ038-R45 COIL 0.45uH
L2601 QQLZ038-R45 COIL 0.45uH
L2602 QQLZ038-R45 COIL 0.45uH
B1 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
B21 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
 CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN102 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN151 QGA3901C1-05 CONNECTOR W-B (1-5)
CN271 QGB2510J1-14 CONNECTOR B-B (1-14)
CN272 QGB2510J1-09 CONNECTOR B-B (1-9)
CN273 QGB2510J1-14 CONNECTOR B-B (1-14)
CN274 QGA3901C1-02 CONNECTOR W-B (1-2)
CN371 QGA2501C1-02 CONNECTOR W-B (1-2)
CN372 QGB2510K2-09 CONNECTOR B-B (1-9)
CN373 QGA2501C1-02 CONNECTOR W-B (1-2)
CN501 QGB2510K2-14 CONNECTOR B-B (1-14)
CN502 QGB2510K2-14 CONNECTOR B-B (1-14)
EP201 QNZ0136-001Z EARTH PLATE
EP501 QNZ0136-001Z EARTH PLATE
FC101 QNG0003-001Z FUSE CLIP
FC102 QNG0003-001Z FUSE CLIP
FC155 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
FC156 QNG0003-001Z FUSE CLIP
FC157 QNG0003-001Z FUSE CLIP
FC158 QNG0003-001Z FUSE CLIP
FW501 QUM213-28Z4Z4 RIBBON WIRE
HS151 QZW0138-001 HEAT SINK
J2701 QND0118-001 DIN CONNECTOR
J2702 QNB0195-001 SPEAKER TERMINA
 RY101 QSK0142-001 RELAY
RY271 QSK0127-001 RELAY
RY272 QSK0127-001 RELAY
RY273 QSK0127-001 RELAY
TH271 QAD0146-103 N THERMISTOR 10k Ω
WC201 QZW0112-001 WIRE CLAMP
X601 QAX0246-001Z C RESONATOR 8.00MHz
 Symbol No. Part No. Part Name Description Local
IC201 LA6502-X IC
IC301 MN2DS0004AA-H IC
IC302 LM1117MP-ADJ-X IC
IC305 MM1563DF-X IC 3.3V Regulator
IC453 S-80830CNNB-G-W IC
IC505 K4S643232F-TC60 IC
IC505 or K4S643232H-TC60 IC
IC509 AT49BV322AT70TI IC(FLASH)
IC509 or MBD32TF70TN IC(MICRO C ROM)
IC512 SN74LVC373APW-X IC(DIGITAL)
IC513 SN74LVC373APW-X IC(DIGITAL)
IC701 AK4384VT-X IC
IC702 AK4384VT-X IC
IC703 AK4384VT-X IC
IC704 CS5342-CZZ-X IC(DIGITAL)
IC705 MM1615AN-X IC
Q101 KTA1001/Y/-X TRANSISTOR
Q101 or 2SB1424/R/-W TRANSISTOR
Q102 2SC4617/R/-X TRANSISTOR
Q103 KTA1001/Y/-X TRANSISTOR
Q103 or 2SB1424/R/-W TRANSISTOR
Q104 2SC4617/R/-X TRANSISTOR
Q105 UN2119-X TRANSISTOR
C101 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C102 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C103 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C104 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C105 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C106 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C107 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C108 NEA70JM-476X E CAPACITOR 47uF 6.3V M
C204 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C205 NCB31HK-271X C CAPACITOR 270pF 50V K
C206 NDC31HJ-151X C CAPACITOR 150pF 50V J
C211 NCB31HK-223X C CAPACITOR 0.022uF 50V K
C217 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C256 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C257 NCB31HK-822X C CAPACITOR 8200pF 50V K
C258 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C259 NCB31CK-153X C CAPACITOR 0.015uF 16V K
C260 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C261 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C262 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C300 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C301 NEA70GM-227X E CAPACITOR 220uF 4V M
C302 NEA70GM-476X E CAPACITOR 47uF 4V M
C303 NEA70GM-476X E CAPACITOR 47uF 4V M
C304 NCB30JK-105X C CAPACITOR 1uF 6.3V K
C305 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C306 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C307 NCB31CK-104X C CAPACITOR 0.1uF 16V K
 Symbol No. Part No. Part Name Description Local
