47
Item Functions and settings
B&W/COLOR (continued)
COLOR
OVERLAY
(TK-C1530U)
COLOUR
OVERLAY
(TK-C1530E/
TK-C1531EG)
This function gives a pseudo color to the image under
natural lighting such as moonlight or low brightness light.
Color reproducibility is poor under artificial illumination
such as infrared lamp and halogen light. In such a case,
select AOFFB for this function.
[Setting: OFF, ON]
[Default setting: OFF]
Memo:
● Even when the MODE item of AUX FUNCTION is set
to AB&W OUTB, B&W OUT will not be output when
this item is set to AONB. To use B&W OUT signal in
external illumination linkage, set this item to AOFFB.
(A Pg. 38)
TK-C1530_EN.book Page 47 Friday, August 24, 2007 9:29 AM
