39
Item Functions and settings
INPUT
POLARITY
This sets the polarity of the AUX input signal.
MAKE : When the contact between all alarm input
terminals and GND terminals changes from
open to close, the alarm will activate.
BREAK : When the contact between all alarm input
terminals and GND terminals changes from
close to open, the alarm will activate.
[Setting: MAKE, BREAK]
[Default setting: MAKE]
Memo:
● When AUX MODE item is set to AB&W OUTB, A- - -B
will be displayed and settings is disabled.
TITLE/VIDEO screen
Item Functions and settings
CAMERA
TITLE EDIT
This item sets the title to be displayed permanently on the
lower part of screen. A maximum of 24 characters can be
set for the title.
ACamera title settingB (A Pg. 54)
W.BALANCE This item sets the white balance function.
Select AAT W B when adjusting the white balance
according to the changes of the object, and select
AAWCB when shooting using adjusted white balance.
Memo:
● In B&W mode, A- - -B will be displayed and settings is
disabled.
● During COLOR OVERLAYAONB or when COLOR
OVERLAY is functioning with AB&W/COLORB mode
set to AAUTOB, A- - -B is displayed and setting is
disabled. (A Pg. 47)(A Pg. 44)
ATW This is the Auto-Tracking White Balance mode.
(Automatic color temperature tracking.) The camera
adjusts the white balance automatically according to the
color temperature of the illumination.
ATW(WI
DE)
This mode supports an even wider range of color
temperature than ATW. Use this mode when white
balance cannot be achieved under a light source such as
high pressure sodium lamp.
TK-C1530_EN.book Page 39 Friday, August 24, 2007 9:29 AM
