Changing camera settings from remote control
This screen allows you to configure title and alarm settings.
(● indicates the default value)
CAMERA TITLE/ALARM
screen
Item Setting value Functions and settings
CAM.TITLE EDIT..
^ This item sets the title to be displayed permanently on the lower left of the
screen. A maximum of 16 characters can be set for the title.
[Camera Title Setting] (A Page 50)
AREA DISPLAY ● OFF
TITLE
DIR
This item sets the area settings.
OFF
^ Settings will not be displayed.
TITLE
^ This item divides the 360° horizontal rotation area into 16 areas and allows you
to set a 16 character title in each area. The area title will be displayed when the
camera is panned manually (horizontal rotation).
[Area Display Mode Setting (Title)] (A Page 51)
DIR
^ This item sets the basic axis direction N (north). When the camera is panned
(horizontal rotation) manually, the 360° horizontal rotation area will be divided
into 8 areas, and N, NE, E, SE, S, SW, W, NW will be displayed respectively for
each area.
[Area Display Mode Setting (Direction)] (A Page 52)
ALM.TITLE SIZE NORMAL
● DOUBLE
This item sets the size of the title displayed during an alarm.
NORMAL:Same size as the text on the menu screen.
DOUBLE:Twice the size vertically and horizontally as the text on the menu
screen.
ALM.TITLE COLOUR ● WHITE
GREEN
CYAN
YELLOW
This item sets the color of the title displayed during an alarm.
ALARM TITLE EDIT..
^ This is the setting screen for the title displayed during an alarm.
[Remote Control Alarm Title Setting] (A Page 53)
ALARM INPUT..
^ This item sets the alarm input terminal.
ALARM INPUT.. This item selects the status of the image output camera during alarm input.
OFF :Does not output images even at alarm input.
HOME :Outputs home position images during alarm input.
POS1 to POS99:
This outputs the video of the selected preset position during alarm input.
Memo ：
● When [B&W MODE] (A Page 35) setting is set to [ALARM IN1 to 6], A(B&W)B
will be displayed and settings is disabled.
ALARM IN1 to 6 ● OFF
HOME
POS1 to POS99
POLARITY ● MAKE
BREAK
This sets the polarity of the alarm input signal.
MAKE :When the contact between all alarm input terminals and GND terminals
changes from open to close, the alarm will activate.
BREAK :When the contact between all alarm input terminals and GND terminals
changes from close to open, the alarm will activate.
Memo ：
● When [ALARM INPUT] item is set to AOFFB, A- - -B will be displayed and
settings is disabled.
