55
3 Press the [SET] button
The [MASK EDIT] screen is displayed. (A frame
appears at the mask area)
Memo :
If the value is set to AOFFB, you will not be able to enter
the [MASK EDIT] screen.
AOUT OF TILT RANGEB will be displayed and Mask
setting is unavailable when the tilt position is 40° and
above from the horizontal direction.
When [MODE] item is set to AOFFB, A- - -B will be
displayed and settings is disabled.
Mask No. 1 to No. 8 are all displayed as (-) at factory
default.
When an edited mask number is selected, the [MASK
EDIT] screen will move to the position that has been set.
4 Set mask area
5 Press the [MENU] button
Save the mask settings and return to the top menu
screen ([MASK MODE] screen).
6 Repeat steps 1 to 4
7 Press the [MENU] button
Level Setting
1
Select [BRIGHT] at the [PRIVATE MASK] screen
Move the cursor (Z) to the [BRIGHT] item, shift the
[PAN/TILT] lever to the left and right and set the
ABRIGHTB (mask color).
The setting value is 0 (black) to 10 (white).
Memo :
To avoid accidental view of masked out area, always
check after setting, and if necessary enlarge mask area
according to step
4 [Set mask area].
When Mask is set at the [MASK EDIT] screen, the setting
value of the [PRIVATE MASK] screen becomes AONB.
After Mask settings are complete, individual ON/OFF
settings can be made for Mask No. 1 to No. 8.
The private mask function will not function during
initialization after power is switched on.
AOUT OF TILT RANGEB will be displayed and Mask
setting is unavailable when the tilt position is 40° and
above from the horizontal direction.
When adjusting the mask position, release the [PAN/TILT]
lever after the tilt angle has reached the horizontal limit,
followed by lowering the lever again to move only the
private mask upwards. Using this operation enables you
to specify a private mask that is beyond the upper limit of
the tilt angle.
[PAN/TILT] lever
(up/down/left/
right)
Edits the mask position
Memo :
When Tilt has stopped at the
horizontal edge, Mask can be set
horizontally above with the
Increased Tilt operation.
[TELE] button
[WIDE] button
Adjusts the size of the mask in the
vertical direction
[NEAR] button
[FAR] button
Adjusts the size of the mask in the
horizontal direction
MASK EDIT No1
<MENU>RETURN
[MASK EDIT] screen
PRIVATE MASK
MODE ON
BRIGHT 4
<
MENU
>
RETURN
<
SET
>
SUB MENU
[PRIVATE MASK] screen
