MOTION DETECT Screen (TK-C9300U/E, TK-C9301EG)
Motion Detect displays the alarm title and outputs an alarm signal when there are
movements in the image. Alarm signal is output from the AUX terminal on the rear
panel.
DETECT LEVEL
Sets the level to detect movements. The larger the value, the higher the
sensitivity. The smaller the value, the lower the sensitivity.
[Setting values : -5 to NORMAL to 5] (Default value: NORMAL)
Memo
Even the flicker of a fluorescent lamp can be detected when a high value
is set.
After setting, make sure to check the operation of the Motion Detect
function using [DEMONSTRATION].
AREA EDIT
Sets the detection area of Motion Detect.
TITLE SIZE
Sets the size of the text displayed when Motion Detect is functioning. When set to
"DOUBLE", the text displayed will be twice the size of the text in the menu.
[Setting values : NORMAL, DOUBLE] (Default value: DOUBLE)
TITLE COLOR (U model), TITLE COLOUR (E/EG model)
Sets the color of the title displayed when Motion Detect is functioning.
[Setting values : WHITE, GREEN, CYAN, YELLOW] (Default value: WHITE)
ALARM TIME
Sets the output time of the alarm signal and the time to display alarm on the
screen.
[Setting values : OFF, 5s to 10s, 15s, 20s, 30s, 60s] (Default value: 5s)
DEMONSTRATION
Use this to check whether the Motion Detect function is set correctly.
Press the [SET] button to start the demonstration.
ADVANCED MENU
12
