20.
21.
22.
23.
24.
25.
26.
VTR
75
©
termination
switch
Set
this
switch
to
75
Q
to
terminate
the
input
signals
of
the
VTR
connected
to
the
8-pin
connector
@
or
to
the
VTR
AUDIO
and
VIDEO
input/out-
put
connectors
@
and
@.
Set
it
to
OPEN
to
make
the
input
signals
of
the
VTR
connected
to
the
8-pin
connector
®
available
at
the
VTR
AUDIO
and
VIDEO
input/output
connectors
@
and
@
.
VTR
AUDIO
input/output
DIN
(5-pin)
socket
:
VTR
VIDEO
input/output
BNC
con-
~nector
Connect
the
audio
and
video
outputs
from
a
video
tape
recorder
or
other
video
sources
to
these
two
connectors.
Or
use
these
connectors
to
produce
signals
bridged
from
the
VTR
connect-
ed
to
the
8-pin
connector
®
.
PAL/AUTO/SECAM
colour
system
select
switch
PAL:
Set
to
this
position
when
the
input
signal
conforms
to
PAL.
AUTO:
The
circuit
is
automatically
switched
either
for
PAL
or
SECAM
depending
on
the
input
signal.
This
position
is
sufficient
for
most
purposes.
SECAM:Set
to
this
position
when
the
input
signal
conforms
to
SECAM.
VIDEO
LINE
IN
BNC
connector
AUDIO
LINE
IN
DIN
(5-pin)
socket
Connect
the
audio
and
video
outputs
from
a
video
tape
recorder
or
other
video
sources
to
be
monitored
to
these
two
connectors.
OUTPUT
VIDEO
BNC
connector
28.
75
Q
27.
OUTPUT
AUDIO
DIN
(5-pin)
socket
Use
these
connectors
to
produce
audio
and
video
signals
being
monitored
with
the
front
panel
input
select
switches
or
bridged
from
the
LINE
connectors
@
and
@.
termination/OUTPUT
select
switch
Set
this
switch
to
75
Q
to
terminate
the
input
signals
connected
to
the
LINE
VIDEO
IN
and
AUDIO
IN
connec-
tors
@
and
@.
Or
set
this
switch
to
OPEN
BRIDGE
OUT
when
you
wish
to
make
available
at
the
OUTPUT
VIDEO
and-AUDIO.
connectors
-@
and
@
signals
connected
to
the
LINE
connectors
@
and
®
.
To
monitor
signals
applied
to
the
8-pin
VTR
connector
@
or
the
audio
and
video
input/
output
connectors
@
and
@,
push
the
front
panel
INPUT
SELECT
“VTR’”’
switch.
To
monitor
signals
applied
to
the
video
and
audio
LINE
connectors
@
and
@,
push
the
front
panel
INPUT
SELECT
“LINE”
switch.
