20
SPECIFICATIONS
MODEL TM-H1950CG TM-H1750CG
Type Color video monitor
Color system PAL, NTSC (3.58)
Picture tube 49 cm (19") measured diagonally, 44 cm (17") measured diagonally,
90° deflection, in-line gun, 90° deflection, in-line gun,
trio-dot type trio-dot type
(phosphor dot-trio pitch 0.27 mm) (phosphor dot-trio pitch 0.27 mm)
Effective screen size Width 365.8 mm (14-5/8") Width 327.5 mm (12-7/8")
Height 274.3 mm (10-7/8") Height 246.2 mm (9-5/8")
Diagonal 457.2 mm (18") Diagonal 407.1 mm (16-1/32")
Scanning frequency H: 15.734 kHz (NTSC), 15.625 kHz (PAL)
V: 59.94 Hz (NTSC) 50 Hz (PAL)
Horizontal resolution 750 TV lines or more
(Y/C input mode)
Input terminals VIDEO A Composite video: 1 line, BNC connector x 2,
1 V(p-p), 75 Ω, negative sync
(bridge connection possible, auto termination)
VIDEO B Composite video: 1 line, BNC connector x 2,
1 V(p-p), 75 Ω, negative sync
(bridge connection possible, auto termination)
Y/C-separated: 1 line, mini-DIN 4-pin connector x 2
Y: 1.0 V (p-p), 75 Ω
C (BURST): 0.286 V (p-p), 75 Ω (NTSC) 0.3 V (p-p), 75 Ω (PAL)
(bridge connection possible, auto termination)
AUDIO A 1 line (monaural), RCA pin x 2, 0.5 V(rms), high-impedance
(bridge connection possible)
AUDIO B 1 line (monaural), RCA pin x 2, 0.5 V(rms), high-impedance
(bridge connection possible)
REMOTE Point-of-contact connection, 1 line D-sub connector (15-pin, 3-line)
Audio power output 1 W
Built-in speaker 8 cm round x 1, impedance of 8 Ω
Environmental conditions Operation temperature: 5°C – 40°C (41°F – 104°F)
Operation humidity: 20 % – 80 % (non-condensing)
Power requirements 120 V/230 V AC, 50 Hz/ 60 Hz
Power consumption 1.3 A (120 V AC)/0.9 A (230 V AC) 1.2 A (120 V AC)/0.8 A (230 V AC)
Dimensions Width 440 mm (17-3/8") Width 395 mm (15-5/8")
Height 375 mm (14-7/8") Height 334 mm (13-1/4")
Depth 496 mm (19-5/8") Depth 418 mm (16-1/2")
Weight 25.6 kg (56.3 lbs) 20.1 kg (44.3 lbs)
(not including input card) (not including input card)
Accessory AC power cord
POWER CORD HOLDER x 1 (case and cover)
Screw x 2 (POWER CORD HOLDER)
* Illustrations used in this manual are for explanatory purposes only. The appearance of the actual product may differ slightly.
* Dimensions and weight are approximate.
* E. & O. E. Design and specifications subject to change without notice.
