2-12
Printed circuit boards
Main board
(forward side) (reverse side)
(forward side) (reverse side)
Trans board
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
