JVC UX-G1 Service Manual

3-9
Power board
Block No. [0][2]
Display board
Block No. [0][3]
L301 OW152040474049 CHOKE COIL 47MH D=6X8mm
L302 OW152040474049 CHOKE COIL 47MH D=6X8mm
L881 OW152004446015 FERRITE COIL 4T 46uH 4X10X2
L882 OW152004446015 FERRITE COIL 4T 46uH 4X10X2
L883 OW152004446015 FERRITE COIL 4T 46uH 4X10X2
T201 OW140000332028 IFT 810017 10mm YEL
T202 OW140001014015 IFT
1A1014N 10mm
RED
T204 OW152086436014 AM ANT COIL 0A10-864367 NP
T360 OW152002072004 RES. BIAC 1A2072N
CF201 OW159050450048 CER FILTER SFU450B 450kHz
CF203 OW160050107076 CER DIS JT10.7 MG82
CF205 OW159050107153 CER FILTER 10.7MS3
CN202 OW260012020055 HEADER 2P for AM ANT
CN203 OW260011020015 HEADER
2P for FM ANT
PCB
CN260 OW260011040033 RED HEADER
4P for DISPLAY
CN103
CN301 OW260011050029 HEADER 5P for C MECH
CN370 OW260011060038 HEADER 6P for C MECH
CN401 OW260011040022 HEADER
4P for DISPLAY
CN105
CN402 OW260011030024 HEADER 3P for CD CN604
CN801 OW260012050036 HEADER
5P for PHONE
CN880
CN802 OW262000006052 HEADER SPK. Terminal
CN850 OW260011070025 HEADER
7P for DISPLAY
CN102
US,UW
CN850 OW260022070025 HEADER
7P for DISPLAY
CN102
UB,UT,
UY
CN851 OW260012030029 HEADER 3P for CD CN605
CN860 OW261042032089 CONNECTOR WIRE
3P for POWER
CN901
FB301 OW166004344022 FERRITE BEAD 600/100MHZ
FB302 OW166004344022 FERRITE BEAD 600/100MHZ
FB809 OW166004344022 FERRITE BEAD 600/100MHZ
FB810 OW166004344022 FERRITE BEAD 600/100MHZ
J259 OW390000029121 C RESISTOR 0
Ω 1/16W
J260 OW390000029121 C RESISTOR 0
Ω 1/16W
UB,UT,
UY
J320 OW390000049315 C RESISTOR 0
Ω 1/8W
J358 OW390000029121 C RESISTOR 0
Ω 1/16W
UB,UT,
UY
JK801 OW270021315006 JACK 3.5mm
LED102 OW313030005076 LED MT-224UBC/W20
LED103 OW313030005076 LED MT-224UBC/W20
TIEIE1 OW235050040011 WIRE 40mm BLK
TIEIE2 OW235050040011 WIRE 40mm BLK
TIEIE3 OW235050040011 WIRE 40mm BLK
TIEIE5 OW235050040011 WIRE 40mm BLK
VD201 SVC348S VARI-CAP DIODE OW300000348027
VD202 SVC201 TUNING DIODE OW300000201016
VD203 SVC201 TUNING DIODE OW300000201016
X260 OW290007200072 CRYSTAL
7.2MHz 20PPM
30pF
XXXXX OW622010001017 SPONGE
For L203
10X10X10mm
UB
XXXXX OW622010001017 SPONGE
For L204
10X10X10mm
UB
XXXXX OW622010001017 SPONGE
For L203
10X10X10mm
US
XXXXX OW622010001017 SPONGE
For L204
10X10X10mm
US
XXXXX OW622010001017 SPONGE
For L203
10X10X10mm
UT
XXXXX OW622010001017 SPONGE
For L204
10X10X10mm
UT
XXXXX OW622010001017 SPONGE
For L203
10X10X10mm
UW
XXXXX OW622010001017 SPONGE
For L204
10X10X10mm
UW
XXXXX OW236092070004 WIRE L=70 BLK for OSC US,UW
XXXXX OW261042052163 CONNECTOR WIRE
5P for PHONE
CN880 to MAIN
CN801
XXXXX OW261041062176 CONNECTOR WIRE
6P For C MECH to
MAIN CN370
XXXXX OW261061053221 CONNECTOR WIRE
5P For C HEAD to
MAIN CN301
 Symbol No. Part No. Part Name Description Local
XXXXX OW169004344163 FERRITE CORE
For Phone to MAIN
PCB
XXXXX OW239084050013 RAINBOW
2P For LIGHT
CN110 to DISPLAY
CN101
XXXXX OW622010001017 SPONGE
For L203
10X10X10mm
UY
XXXXX OW622010001017 SPONGE
For L204
10X10X10mm
UY
XXXXX OW173000300027 FM ANT For RF2
XXXXX OW261041021421 WIRE
1P For MAIN
CN203 to RF2
XXXXX OW263092070004 WIRE L=70 BLK for OSC
UB,UT,
UY
XXXXX OW555020001109 MAIN PCB 94V0 1.6 OSP
XXXXX OW603000003022 CABLE TIE 4UL
ZD201 10V0.5W Z DIODE OW303050100043
ZD830 9.1V0.5W Z DIODE OW303050091034
ZD860 6.8V0.5W Z DIODE OW303050068044
ZD861 6.2V0.5W Z DIODE OW303050062074
 Symbol No. Part No. Part Name Description Local
 D901 RL202 DIODE OW300000202061
 D902 RL202 DIODE OW300000202061
 D903 RL202 DIODE OW300000202061
 D904 RL202 DIODE OW300000202061
 D905 1N4001 DIODE OW300004001048
 D906 1N4001 DIODE OW300004001048
 D907 1N4001 DIODE OW300004001048
 D908 1N4001 DIODE OW300004001048
 C901 OW130103037211 E CAPACITOR 1000uF 25V
C902 OW100104069003 C CAPACITOR 0.1uF
C903 OW100223069009 C CAPACITOR 0.022uF
C904 OW100223069009 C CAPACITOR 0.022uF
C905 OW100223069009 C CAPACITOR 0.022uF
C906 OW100223069009 C CAPACITOR 0.022uF
 C907 OW130103037211 E CAPACITOR 1000uF 25V
C908 OW100223069009 C CAPACITOR 0.022uF
C909 OW100223069009 C CAPACITOR 0.022uF
C910 OW100223069009 C CAPACITOR 0.022uF
C911 OW100223069009 C CAPACITOR 0.022uF
C912 OW100223069009 C CAPACITOR 0.022uF
CN901 OW260012030031 HEADER 3P for MAIN CN860
XXXXX OW169004344117 FERRITE CORE For AC Cord
XXXXX OW555020001133 POWER PCB 94V0 1.6mm
XXXXX OW235020047019 UL WIRE 5/47/5 Brown
XXXXX OW235020240011 UL WIRE 5/230/5 Blue
XXXXX OW607000002011 EYELET 2X4mm(x8)
XXXXX OW603000003022 CABLE TIE 4UL(x3)
 Symbol No. Part No. Part Name Description Local
IC101 OW510087261199 IC TMP87EP26F US
IC101 OW510087261209 IC TMP87EP26F UW
Q101 9014 TRANSISTOR OW343009014064
Q102 9014 TRANSISTOR OW343009014064
Q103 9018 TRANSISTOR OW343009018047
D101 1N4148 DIODE OW300004148072
D102 1N4148 DIODE OW300004148072
D103 1N4148 DIODE OW300004148072
 Symbol No. Part No. Part Name Description Local
