JVC UX-G1 Service Manual

3-10
CD board
Block No. [0][4]
D104 1N4148 DIODE OW300004148072
D105 ELT-3142D LED OW313030022042
C103 OW133103007014 E CAPACITOR 1000uF 6.3V
C104 OW133103007014 E CAPACITOR 1000uF 6.3V
C105 OW120104527009 C CAPACITOR 0.1uF 50V
C106 OW120240526009 C CAPACITOR 24pF 50V
C107 OW120560526008 C CAPACITOR 56pF 50V
C108 OW120240526009 C CAPACITOR 24pF 50V
C109 OW130101017114 E CAPACITOR 10uF 10V
C110 OW120104527009 C CAPACITOR 0.1uF 50V
C111 OW120200526002 C CAPACITOR 20pF 50V
C114 OW120200526002 C CAPACITOR 20pF 50V
C115 OW120104527009 C CAPACITOR 0.1uF 50V
C116 OW120223527006 C CAPACITOR 0.022uF 50V
C117 OW120223527006 C CAPACITOR 0.022uF 50V
C118 OW130471017115 E CAPACITOR 47uF 10V
C119 OW130222017112 E CAPACITOR 220uF 10V
C125 OW120104527009 C CAPACITOR 0.1uF 50V
C118A OW120104527009 C CAPACITOR 0.1uF 50V
R101 OW390150126104 C RESISTOR 1.5K
Ω 1/16W
R102 OW390150126104 C RESISTOR 1.5K
Ω 1/16W
R103 OW390150126104 C RESISTOR 1.5K
Ω 1/16W
R104 OW390470126103 C RESISTOR 4.7K
Ω 1/16W
R105 OW390000029121 C RESISTOR 0
Ω 1/16W
R106 OW390100226108 C RESISTOR 10K
Ω 1/16W
R107 OW390100226108 C RESISTOR 10K
Ω 1/16W
R108 OW390100126102 C RESISTOR 1K
Ω 1/16W
R109 OW390150226101 C RESISTOR 15K
Ω 1/16W
R110 OW390100226108 C RESISTOR 10K
Ω 1/16W
R111 OW390100226108 C RESISTOR 10K
Ω 1/16W
R112 OW390100226108 C RESISTOR 10K
Ω 1/16W
R113 OW390100226108 C RESISTOR 10K
Ω 1/16W
R114 OW390100226108 C RESISTOR 10K
Ω 1/16W
R115 OW390100226108 C RESISTOR 10K
Ω 1/16W
R117 OW390220126104 C RESISTOR 2.2K
Ω 1/16W
R118 OW390470126103 C RESISTOR 4.7K
Ω 1/16W
R119 OW390470126103 C RESISTOR 4.7K
Ω 1/16W
R120 OW390470126103 C RESISTOR 4.7K
Ω 1/16W
R122 OW390100226108 C RESISTOR 10K
Ω 1/16W
R123 OW390150126104 C RESISTOR 1.5K
Ω 1/16W
R124 OW390270126106 C RESISTOR 2.7K
Ω 1/16W
R125 OW390100226108 C RESISTOR 10K
Ω 1/16W
R126 OW390100226108 C RESISTOR 10K
Ω 1/16W
R127 OW390100226108 C RESISTOR 10K
Ω 1/16W
R128 OW390100126102 C RESISTOR 1K
Ω 1/16W
R130 OW390470026106 C RESISTOR 470
Ω 1/16W
R131 OW390680026107 C RESISTOR 680
Ω 1/16W
R132 OW390820026107 C RESISTOR 820
Ω 1/16W
R133 OW390220926107 C RESISTOR 22
Ω 1/16W
R134 OW390100126102 C RESISTOR 1K
Ω 1/16W
R135 OW390470026106 C RESISTOR 470
Ω 1/16W
R136 OW390220926107 C RESISTOR 22
Ω 1/16W
R137 OW390680026107 C RESISTOR 680
Ω 1/16W
R138 OW390820026107 C RESISTOR 820
Ω 1/16W
R139 OW390100126102 C RESISTOR 1K
Ω 1/16W
R140 OW390120126101 C RESISTOR 1.2K
Ω 1/16W
R141 OW390150126104 C RESISTOR 1.5K
Ω 1/16W
R142 OW390100226108 C RESISTOR 10K
Ω 1/16W
R143 OW390100226108 C RESISTOR 10K
Ω 1/16W
R144 OW390100126102 C RESISTOR 1K
Ω 1/16W
R145 OW390100226108 C RESISTOR 10K
Ω 1/16W
R146 OW390100226108 C RESISTOR 10K
Ω 1/16W
R147 OW390100226108 C RESISTOR 10K
Ω 1/16W
R148 OW390100226108 C RESISTOR 10K
Ω 1/16W
R149 OW390100226108 C RESISTOR 10K
Ω 1/16W
R150 OW390100226108 C RESISTOR 10K
Ω 1/16W
R151 OW390100226108 C RESISTOR 10K
Ω 1/16W
R152 OW390100226108 C RESISTOR 10K
Ω 1/16W
R153 OW390100226108 C RESISTOR 10K
Ω 1/16W
R154 OW390100226108 C RESISTOR 10K
Ω 1/16W
R155 OW390330126102 C RESISTOR 3.3K
Ω 1/16W
R156 OW390100226108 C RESISTOR 10K
Ω 1/16W
R157 OW390100226108 C RESISTOR 10K
Ω 1/16W
R158 OW390100126102 C RESISTOR 1K
Ω 1/16W
R159 OW390100226108 C RESISTOR 10K
Ω 1/16W
R160 OW390100226108 C RESISTOR 10K
Ω 1/16W
 Symbol No. Part No. Part Name Description Local
R161 OW390100226108 C RESISTOR 10K Ω 1/16W
UB,UT,
UY
R162 OW390100226108 C RESISTOR 10K
Ω 1/16W
R163 OW390100926105 C RESISTOR 10
Ω 1/16W
L101 OW162070102075 COIL 100uH
L104 OW166004344011 FERRITE BEAD 700
Ω 100MHz
CN102 OW261041071086 CONNECTOR WIRE 7P for MAIN CN850
CN103 OW261041041194 CONNECTOR WIRE 4P for MAIN CN260
CN104 OW261041102143 CONNECTOR WIRE 10P for CD CN606
CN105 OW261041041183 CONNECTOR WIRE 4P for MAIN CN401
CN107 OW261041021387 CONNECTOR WIRE
2P for CD door
switch
CN109 OW261041032238 CONNECTOR WIRE 3P for CD CN603
J133 OW390000029121 C RESISTOR 0
Ω 1/16W
J134 OW390000029121 C RESISTOR 0
Ω 1/16W
J136 OW390000049315 C RESISTOR 0
Ω 1/8W
J138 OW390000049315 C RESISTOR 0
Ω 1/8W
J141 OW390000029121 C RESISTOR 0
Ω 1/16W
LCD101 OW351020001008 LCD G8023TT-P
SEN102 OW309066038031 REMOTE SENSOR FM-6038TM2-5AN US,UW
SEN102 OW309062638005 REMOTE SENSOR
IRM2638F4
EVERLIGHT
UB,UT,
UY
SW101 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW102 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW103 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW104 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW105 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW106 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW107 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW108 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW109 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW110 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW111 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
SW112 OW182010101194 TACT SWITCH
Evqjae 05R
H=5mm
X101 OW156050720026 CER. RESONATOR ZTA7.2MT
X102 OW290032768078 CRYSTAL 32.768MHz 20PPM
XXXXX OW239084070018 CONNECTOR WIRE
3P for DISPLAY
CN106 to KEY
CN108
XXXXX OW555020001033 DISPLAY PCB
W/04/11 94HB
1.6mm
 Symbol No. Part No. Part Name Description Local
IC601 TC94A14FA CD LSI IC OW510009414017
IC602 TA2157FN IC OW510002157016
IC603 TA2092AN IC OW510002092038
IC604 TC94A02F-007 IC OW510009402012
IC605 AS7C31024B-15 IC OW510031024039
IC606 SN74HC14DR IC OW510007414038
 IC607 PJ7805 IC OW510007805103
Q601 8050D TRANSISTOR OW343008050075
Q602 8050D TRANSISTOR OW343008050075
Q603 8050D TRANSISTOR OW343008050075
Q604 8050D TRANSISTOR OW343008050075
Q605 2SA733PNP TRANSISTOR OW343000733056
Q608 8050 TRANSISTOR OW343008050064
 Symbol No. Part No. Part Name Description Local
