3.1.7 Removing the Display board (See Fig.16)
(1) Remove the Volume knob.
(2) Remove the thirteen screws L attaching the Display board.
Fig.16
3.1.8 Removing the USB board (See Fig.17)
(1) Remove the six screws M attaching the USB board.
Fig.17
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.
