JVC UX-G375A User Manual

3-6
Electrical parts list
MCU board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
IC201 1506780515000-C IC 1506-780515000
IC202 CD1511002402080 IC 1511-002402080
IC204 CD1502002314010 IC 1502-002314010
IC205 CD1502004453000 IC 1502-004453000
IC212 CD1502007492010 IC 1502-007492010
Q1 CD1421085500010 TRANSISTOR 1421-085500010
Q201 CD1422080500050 TRANSISTOR 1422-080500050
Q202 CD1411085500000 TRANSISTOR 1411-085500000
Q203 CD1422080500050 TRANSISTOR 1422-080500050
Q204 CD1422080500050 TRANSISTOR 1422-080500050
Q205 CD1424023010010 MOSFET 1424-023010010
Q206 CD1422080500050 TRANSISTOR 1422-080500050
Q207 CD1412080500000 TRANSISTOR 1412-080500000
Q212 CD1412080500000 TRANSISTOR 1412-080500000
Q213 CD1424230180010 MOS FET 1424-230180010 D,E,I,J,
K,L,M
Q217 CD1422080500050 TRANSISTOR 1422-080500050
Q218 CD1422080500050 TRANSISTOR 1422-080500050
Q219 CD1422080500050 TRANSISTOR 1422-080500050
D1 CD1321041480050 DIODE 1321-041480050
D2 CD1321041480050 DIODE 1321-041480050
D3 CD1321041480050 DIODE 1321-041480050
D6 CD1321041480050 DIODE 1321-041480050
D7 CD1321041480050 DIODE 1321-041480050
D201 CD1321041480050 DIODE 1321-041480050
D202 CD1321041480050 DIODE 1321-041480050
D203 CD1321041480050 DIODE 1321-041480050
D206 CD1321041480050 DIODE 1321-041480050
C1 CD1121103082020 C CAPACITOR 1121-103082020
C2 CD1132225083060 E CAPACITOR 1132-225083060
C3 CD1121103082020 C CAPACITOR 1121-103082020
C5 CD1121102082020 C CAPACITOR 1121-102082020 A,B,C,
D,E,F,
G,H,I ,J,
K,L
C5 CD1121102082021 C CAPACITOR 1121-102082021 M
C6 CD1121102082020 C CAPACITOR 1121-102082020 A,B,C,
D,E,F,
G,H,I ,J,
K,L
C6 CD1121102082021 C CAPACITOR 1121-102082021 M
C9 CD1138474091210 M CAPACITOR 1138-474091210
C10 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I ,J,
K,L
C10 CD1121105052020 C CAPACITOR 1121-105052020 M
C11 CD1121104082020 C CAPACITOR 1121-104082020
C16 CD1121103082020 C CAPACITOR 1121-103082020
C17 CD1121103082020 C CAPACITOR 1121-103082020
C18 CD1121103082020 C CAPACITOR 1121-103082020
C19 CD1121103082020 C CAPACITOR 1121-103082020
C20 CD1121224084020 C CAPACITOR 1121-224084020
C21 CD1121224084020 C CAPACITOR 1121-224084020
C22 CD1121224084020 C CAPACITOR 1121-224084020
C23 CD1121224084020 C CAPACITOR 1121-224084020
C7B CD1121104082020 C CAPACITOR 1121-104082020
C8B CD1121104082020 C CAPACITOR 1121-104082020
C201 CD1121102082020 C CAPACITOR 1121-102082020 D,E,I,J,
K,L
C201 CD1121102082021 C CAPACITOR 1121-102082021 M
C202 CD1221000062020 C RESISTOR 1221-000062020 D,E,I,J,
K,L,M
C207 CD1221304062020 C RESISTOR 1221-304062020 D,E,I,J,
K,L,M
C208 CD1221000062020 C RESISTOR 1221-000062020 D,E,I,J,
K,L,M
C210 CD1121104082020 C CAPACITOR 1121-104082020
C220 CD1121104082020 C CAPACITOR 1121-104082020
C221 CD1121104082020 C CAPACITOR 1121-104082020
C222 CD1121104082020 C CAPACITOR 1121-104082020
C223 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C223 CD1121105052020 C CAPACITOR 1121-105052020 M
C224 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C224 CD1121105052020 C CAPACITOR 1121-105052020 M
C225 CD1132225083060 E CAPACITOR 1132-225083060
C226 CD1121104082020 C CAPACITOR 1121-104082020
C227 CD1121104082020 C CAPACITOR 1121-104082020
C228 CD1121104082020 C CAPACITOR 1121-104082020
C229 CD1132158073271 E CAPACITOR 1132-158073271
C230 CD1121331081020 C CAPACITOR 1121-331081020
C231 CD1138474091210 M CAPACITOR 1138-474091210
C232 CD1121224084020 C CAPACITOR 1121-224084020
C233 CD1121224084020 C CAPACITOR 1121-224084020
C234 CD1138474091210 M CAPACITOR 1138-474091210
C235 CD1121224084020 C CAPACITOR 1121-224084020
C236 CD1121224084020 C CAPACITOR 1121-224084020
C237 CD1121474084020 C CAPACITOR 1121-474084020
C238 CD1121474084020 C CAPACITOR 1121-474084020
C239 CD1121104082020 C CAPACITOR 1121-104082020
C240 CD1121474084020 C CAPACITOR 1121-474084020
C241 CD1121681081020 C CAPACITOR 1121-681081020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C241 CD1121681081021 C CAPACITOR 1121-681081021 M
C242 CD1121681081020 C CAPACITOR 1121-681081020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C242 CD1121681081021 C CAPACITOR 1121-681081021 M
C243 CD1121474084020 C CAPACITOR 1121-474084020
C244 CD1121104082020 C CAPACITOR 1121-104082020
C245 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C245 CD1121105052020 C CAPACITOR 1121-105052020 M
C246 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C246 CD1121105052020 C CAPACITOR 1121-105052020 M
C247 CD1121104082020 C CAPACITOR 1121-104082020
C256 CD1121104082020 C CAPACITOR 1121-104082020
C257 CD1132227053320 E CAPACITOR 1132-227053320
C258 CD1132227053320 E CAPACITOR 1132-227053320
C260 CD1121104082020 C CAPACITOR 1121-104082020
C262 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C262 CD1121105052020 C CAPACITOR 1121-105052020 M
C264 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C264 CD1121105052020 C CAPACITOR 1121-105052020 M
C265 CD1132476053050 E CAPACITOR 1132-476053050
C266 CD1132227053320 E CAPACITOR 1132-227053320
C267 CD1132476053050 E CAPACITOR 1132-476053050
C268 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C268 CD1121105052020 C CAPACITOR 1121-105052020 M
C269 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I,J,
K,L
C269 CD1121105052020 C CAPACITOR 1121-105052020 M
C270 CD1121104082020 C CAPACITOR 1121-104082020
C271 CD1132107053060 E CAPACITOR 1132-107053060
C272 CD1132476053060 E CAPACITOR 1132-476053060
 Symbol No. Part No. Part Name Description Local
