JVC UX-G375A

3-10
Display board
Block No. [0][3]
 Symbol No. Part No. Part Name Description Local
U501 CD1513016315010 IC 1513-016315010
CH01 CD1121101082020 C CAPACITOR 1121-101082020
CH02 CD1121101082020 C CAPACITOR 1121-101082020
CH03 CD1121102082020 C CAPACITOR 1121-102082020 A,B,C,
D,E,F,
G,H,I ,
J,K,L
CH03 CD1121102082021 C CAPACITOR 1121-102082021 M
CH04 CD1121102082020 C CAPACITOR 1121-102082020 A,B,C,
D,E,F,
G,H,I ,
J,K,L
CH04 CD1121102082021 C CAPACITOR 1121-102082021 M
CH05 CD8022000000600 PULSE GUARD 8022-000000600
CH06 CD8022000000600 PULSE GUARD 8022-000000600
CH07 CD8022000000600 PULSE GUARD 8022-000000600
CH08 CD8022000000600 PULSE GUARD 8022-000000600
CK401 CD1121104082020 C CAPACITOR 1121-104082020
CK402 CD1121102082020 C CAPACITOR 1121-102082020 A,B,C,
D,E,F,
G,H,I ,
J,K,L
CK402 CD1121102082021 C CAPACITOR 1121-102082021 M
CK403 CD1121102082020 C CAPACITOR 1121-102082020 A,B,C,
D,E,F,
G,H,I ,
J,K,L
CK403 CD1121102082021 C CAPACITOR 1121-102082021 M
CK404 CD1121104082020 C CAPACITOR 1121-104082020
CK405 CD1121104082020 C CAPACITOR 1121-104082020
CN41 CD3106101621020 FFC CONNECTOR 3106-101621020
CN42 CD3505020182000 CONNECTOR WIRE 3505-020182000 A,B,C,
E,F,G,
H,I,J,
K,M
CN42 CD3505020242000 CONNECTOR WIRE 3505-020242000 D,L
CP41 CD3505070362020 CONNECTOR WIRE 3505-070362020
CP42 CD3505030332000 CONNECTOR WIRE 3505-030332000
CP45 CD3502020202500 CONNECTOR WIRE 3502-020202500 A,B,C,
E,F,G,
H,I,J,
K,M
CP45 CD3505020232500 CONNECTOR WIRE 3505-020232500 D,L
CV503 CD1121104082020 C CAPACITOR 1121-104082020
CV504 CD1121104082020 C CAPACITOR 1121-104082020
CV505 CD1121104082020 C CAPACITOR 1121-104082020
CV515 CD1121104082020 C CAPACITOR 1121-104082020
CV516 CD1121104082020 C CAPACITOR 1121-104082020
CV517 CD1121104082020 C CAPACITOR 1121-104082020
CV521 CD1121221082020 C CAPACITOR 1121-221082020
CV522 CD1121221082020 C CAPACITOR 1121-221082020
CV525 CD1121221082020 C CAPACITOR 1121-221082020
CV526 CD1121221082020 C CAPACITOR 1121-221082020
CV527 CD1121221082020 C CAPACITOR 1121-221082020
DK401 CD1321140010010 DIODE 1321-140010010 A,B,C,
E,F,G,
H,I,J,
K,M
DV501 CD1322005200020 BARRIER DIODE 1322-005200020
EC412 CD1132107053090 E CAPACITOR 1132-107053090
EC501 CD1132107053090 E CAPACITOR 1132-107053090
EC502 CD1132107053090 E CAPACITOR 1132-107053090
EC503 CD1132106083080 E CAPACITOR 1132-106083080
EC504 CD1132106083080 E CAPACITOR 1132-106083080
EC505 CD1132476073200 E CAPACITOR 1132-476073200
EC506 CD1132227053320 E CAPACITOR 1132-227053320
FB41 CD2721272030010 FERRITE BEAD 2721-272030010
FB42 CD2721272030010 FERRITE BEAD 2721-272030010
FB43 CD1221000062020 C RESISTOR 1221-000062020
FB44 CD1221000062020 C RESISTOR 1221-000062020
FB401 CD2721101020000 FERRITE BEAD 2721-101020000
FB402 CD2721101020000 FERRITE BEAD 2721-101020000
FB403 CD2721101020000 FERRITE BEAD 2721-101020000
FB404 CD2721101020000 FERRITE BEAD 2721-101020000
FB502 CD2721101020000 FERRITE BEAD 2721-101020000
FB503 CD2721101020000 FERRITE BEAD 2721-101020000
FB504 CD2721101020000 FERRITE BEAD 2721-101020000
FB505 CD2721101020000 FERRITE BEAD 2721-101020000
FB506 CD2721101020000 FERRITE BEAD 2721-101020000
FB507 CD2721101020000 FERRITE BEAD 2721-101020000
FB508 CD2721101020000 FERRITE BEAD 2721-101020000
FB509 CD2721101020000 FERRITE BEAD 2721-101020000
FB510 CD2721101020000 FERRITE BEAD 2721-101020000
FB511 CD2721101020000 FERRITE BEAD 2721-101020000
IR401 CD1801000000270 IR RECEIVER 1801-000000270
JK41 CD3203070225000 PHONE JACK 3203-070225000
JK42 CD3203070225000 PHONE JACK 3203-070225000
JK43 CD3209040100030 USB JACK 3209-040100030
LED1 CD1316033470000 LED 1316-033470000
LED3 CD1316034000000 LED 1316-034000000
LH01 CD2721272030010 FERRITE BEAD 2721-272030010
LH02 CD2721272030010 FERRITE BEAD 2721-272030010
LH03 CD1606100120000 COIL 1606-100120000
LH04 CD1606100120000 COIL 1606-100120000
PTC01 CD1214033000001 THERMISTOR 1214-033000001
QK402 CD1422080500050 TRANSISTOR 1422-080500050
QK403 CD1422080500050 TRANSISTOR 1422-080500050
QK404 CD1422080500050 TRANSISTOR 1422-080500050
QK405 CD1421085500010 TRANSISTOR 1421-085500010
QV506 CD1412080500000 TRANSISTOR 1412-080500000
QV507 CD1411085500000 TRANSISTOR 1411-085500000
RH01 CD1221511062020 C RESISTOR 1221-511062020
RH02 CD1221511062020 C RESISTOR 1221-511062020
RK401 CD1221681062020 C RESISTOR 1221-681062020
RK402 CD1221222062020 C RESISTOR 1221-222062020
RK403 CD1221101062020 C RESISTOR 1221-101062020
RK404 CD1221101062020 C RESISTOR 1221-101062020
RK405 CD1221101062020 C RESISTOR 1221-101062020
RK406 CD1221101062020 C RESISTOR 1221-101062020
RK410 CD1221103062020 C RESISTOR 1221-103062020
RK411 CD1221471062020 C RESISTOR 1221-471062020
RK412 CD1221182062020 C RESISTOR 1221-182062020
RK413 CD1221272062020 C RESISTOR 1221-272062020
RK414 CD1221332062020 C RESISTOR 1221-332062020
RK415 CD1221392062020 C RESISTOR 1221-392062020
RK416 CD1221752062020 C RESISTOR 1221-752062020
RK417 CD1221103062020 C RESISTOR 1221-103062020
RK418 CD1221103062020 C RESISTOR 1221-103062020
RK419 CD1221222062020 C RESISTOR 1221-222062020
RK421 CD1221222062020 C RESISTOR 1221-222062020
RK423 CD1221222062020 C RESISTOR 1221-222062020
RK424 CD1221103062020 C RESISTOR 1221-103062020
RK425 CD1221222062020 C RESISTOR 1221-222062020
RK431 CD1221471062020 C RESISTOR 1221-471062020
RK432 CD1221182062020 C RESISTOR 1221-182062020
RK433 CD1221272062020 C RESISTOR 1221-272062020
RK434 CD1221332062020 C RESISTOR 1221-332062020
RK435 CD1221392062020 C RESISTOR 1221-392062020
RV501 CD1221103062020 C RESISTOR 1221-103062020
RV502 CD1221101022050 C RESISTOR 1221-101022050
RV503 CD1221221062020 C RESISTOR 1221-221062020
RV504 CD1221221062020 C RESISTOR 1221-221062020
RV505 CD1221221062020 C RESISTOR 1221-221062020
RV506 CD1221203062020 C RESISTOR 1221-203062020
RV507 CD1221471062020 C RESISTOR 1221-471062020
RV508 CD1221471062020 C RESISTOR 1221-471062020
RV509 CD1221123062020 C RESISTOR 1221-123062020
RV518 CD1221103062020 C RESISTOR 1221-103062020
RV519 CD1221103062020 C RESISTOR 1221-103062020
RV520 CD1221471062020 C RESISTOR 1221-471062020
RV521 CD1221221062020 C RESISTOR 1221-221062020
RV522 CD1221102062020 C RESISTOR 1221-102062020
RV523 CD1221151062020 C RESISTOR 1221-151062020
SW401 CD3302010143060 TACT SWITCH 3302-010143060
SW402 CD3302010143060 TACT SWITCH 3302-010143060
SW403 CD3302010143060 TACT SWITCH 3302-010143060
SW404 CD3302010143060 TACT SWITCH 3302-010143060
SW405 CD3302010143060 TACT SWITCH 3302-010143060
SW406 CD3302010143060 TACT SWITCH 3302-010143060
SW407 CD3302010143060 TACT SWITCH 3302-010143060
SW408 CD3302010143060 TACT SWITCH 3302-010143060
SW410 CD3302010143060 TACT SWITCH 3302-010143060
SW411 CD3302010143060 TACT SWITCH 3302-010143060
SW412 CD3302010143060 TACT SWITCH 3302-010143060
 Symbol No. Part No. Part Name Description Local
