CD board
Block No. [0][4]
SW413 CD3302010143060 TACT SWITCH 3302-010143060
SW501 CD3300000000130 ENCODER 3300-000000130
ZD41 CD1323003510000 Z DIODE 1323-003510000
ZD42 CD1323003510000 Z DIODE 1323-003510000
ZD43 CD1323003510000 Z DIODE 1323-003510000
ZD44 CD1323003510000 Z DIODE 1323-003510000
ZD405 CD1313055390000 Z DIODE 1313-055390000
ZD501 CD1313055270000 Z DIODE 1313-055270000
ZD502 CD1313055560020 Z DIODE 1313-055560020
ZD503 CD1323003510000 Z DIODE 1323-003510000
ZD504 CD1323003510000 Z DIODE 1323-003510000
ZD505 CD1323003510000 Z DIODE 1323-003510000
ZD506 CD1323003510000 Z DIODE 1323-003510000
ZD507 CD1313055470010 Z DIODE 1313-055470010
ZD508 CD1313055560020 Z DIODE 1313-055560020
 Symbol No. Part No. Part Name Description Local
IC101 CD1512001117130 IC 1512-001117130
IC102 CD1512001117080 IC 1512-001117080
IC103 CD1511981616030 IC 1511-981616030
IC104 CD1513005888020 IC 1513-005888020
IC105 CD1511002540000 IC 1511-002540000
IC106 CD1509008104020 IC 1509-008104020
Q101 CD1422080500050 TRANSISTOR 1422-080500050
Q102 CD1421211320010 TRANSISTOR 1421-211320010
Q103 CD1422080500050 TRANSISTOR 1422-080500050
Q104 CD1422080500050 TRANSISTOR 1422-080500050
Q105 CD1424023010010 MOSFET 1424-023010010
Q106 CD1412080500000 TRANSISTOR 1412-080500000
Q107 CD1412080500000 TRANSISTOR 1412-080500000
Q108 CD1411085500000 TRANSISTOR 1411-085500000
Q109 CD1411085500000 TRANSISTOR 1411-085500000
D101 CD1311140010040 DIODE 1311-140010040
D102 CD1321041480050 DIODE 1321-041480050
D103 CD1321041480050 DIODE 1321-041480050
D104 CD1321041480050 DIODE 1321-041480050
D110 CD1321041480050 DIODE 1321-041480050
D111 CD1321041480050 DIODE 1321-041480050
C1 CD1121103082020 C CAPACITOR 1121-103082020
C3 CD1121103082020 C CAPACITOR 1121-103082020
C100 CD1121104082020 C CAPACITOR 1121-104082020
C101 CD1121104082020 C CAPACITOR 1121-104082020
C102 CD1132227053060 E CAPACITOR 1132-227053060
C103 CD1121104082020 C CAPACITOR 1121-104082020
C104 CD1132227053060 E CAPACITOR 1132-227053060
C105 CD1121104082020 C CAPACITOR 1121-104082020
C106 CD1132106053060 E CAPACITOR 1132-106053060
C107 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I,
J,K,L
C107 CD1121105052020 C CAPACITOR 1121-105052020 M
C108 CD1121104082020 C CAPACITOR 1121-104082020
C109 CD1132107053060 E CAPACITOR 1132-107053060
C110 CD1121104082020 C CAPACITOR 1121-104082020
C111 CD1132107053060 E CAPACITOR 1132-107053060
C112 CD1121104082020 C CAPACITOR 1121-104082020
C113 CD1121100081020 C CAPACITOR 1121-100081020
C114 CD1121104082020 C CAPACITOR 1121-104082020
C115 CD1121470081020 C CAPACITOR 1121-470081020
C116 CD1121470081020 C CAPACITOR 1121-470081020
C117 CD1121104082020 C CAPACITOR 1121-104082020
C118 CD1132107053710 E CAPACITOR 1132-107053710
C119 CD1121104082020 C CAPACITOR 1121-104082020
C120 CD1121104082020 C CAPACITOR 1121-104082020
C121 CD1121104082020 C CAPACITOR 1121-104082020
C122 CD1132106053060 E CAPACITOR 1132-106053060
C123 CD1121104082020 C CAPACITOR 1121-104082020
 Symbol No. Part No. Part Name Description Local
C124 CD1132107053060 E CAPACITOR 1132-107053060
C127 CD1132477053220 E CAPACITOR 1132-477053220
C129 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I ,
J,K,L
C129 CD1121105052020 C CAPACITOR 1121-105052020 M
C131 CD1121104082020 C CAPACITOR 1121-104082020
C132 CD1121104082020 C CAPACITOR 1121-104082020
C133 CD1121104082020 C CAPACITOR 1121-104082020
C134 CD1132107053060 E CAPACITOR 1132-107053060
C135 CD1121102082020 C CAPACITOR 1121-102082020 A,B,C,
D,E,F,
G,H,I ,
J,K,L
C135 CD1121102082021 C CAPACITOR 1121-102082021 M
C136 CD1121104082020 C CAPACITOR 1121-104082020
C137 CD1121104082020 C CAPACITOR 1121-104082020
C138 CD1121101082020 C CAPACITOR 1121-101082020
C139 CD1121510081020 C CAPACITOR 1121-510081020
C140 CD1121510081020 C CAPACITOR 1121-510081020
C146 CD1121104082020 C CAPACITOR 1121-104082020
C147 CD1121104082020 C CAPACITOR 1121-104082020
C148 CD1121105051020 C CAPACITOR 1121-105051020 A,B,C,
D,E,F,
G,H,I ,
J,K,L
C148 CD1121105052020 C CAPACITOR 1121-105052020 M
C149 CD1121104082020 C CAPACITOR 1121-104082020
C150 CD1132476053060 E CAPACITOR 1132-476053060
C151 CD1132476053060 E CAPACITOR 1132-476053060
C152 CD1121104082020 C CAPACITOR 1121-104082020
C155 CD1121103082020 C CAPACITOR 1121-103082020
C156 CD1121103082020 C CAPACITOR 1121-103082020
C157 CD1121103082020 C CAPACITOR 1121-103082020
C158 CD1132107053060 E CAPACITOR 1132-107053060
C159 CD1121104082020 C CAPACITOR 1121-104082020
C160 CD1121104082020 C CAPACITOR 1121-104082020
C161 CD1132107053060 E CAPACITOR 1132-107053060
C162 CD1121104082020 C CAPACITOR 1121-104082020
C163 CD1132476053060 E CAPACITOR 1132-476053060
C164 CD1121104082020 C CAPACITOR 1121-104082020
C165 CD1121152082020 C CAPACITOR 1121-152082020
C166 CD1121102082020 C CAPACITOR 1121-102082020 A,B,C,
D,E,F,
G,H,I ,
J,K,L
C166 CD1121102082021 C CAPACITOR 1121-102082021 M
C167 CD1121104082020 C CAPACITOR 1121-104082020
C168 CD1132477053220 E CAPACITOR 1132-477053220
C169 CD1121104082020 C CAPACITOR 1121-104082020
C170 CD1121104082020 C CAPACITOR 1121-104082020
C171 CD1121104082020 C CAPACITOR 1121-104082020
C172 CD1132106053060 E CAPACITOR 1132-106053060
C173 CD1121104082020 C CAPACITOR 1121-104082020
C174 CD1121104082020 C CAPACITOR 1121-104082020
C177 CD1132476053060 E CAPACITOR 1132-476053060
C178 CD1132476053060 E CAPACITOR 1132-476053060
C179 CD1121104082020 C CAPACITOR 1121-104082020
C180 CD1121104082020 C CAPACITOR 1121-104082020
C186 CD1121104082020 C CAPACITOR 1121-104082020
C187 CD1121104082020 C CAPACITOR 1121-104082020
C192 CD1121104082020 C CAPACITOR 1121-104082020
C193 CD1121104082020 C CAPACITOR 1121-104082020
C194 CD1121104082020 C CAPACITOR 1121-104082020
C195 CD1121104082020 C CAPACITOR 1121-104082020
C196 CD1121104082020 C CAPACITOR 1121-104082020
R1 CD1221562062020 C RESISTOR 1221-562062020
R3 CD1231047022000 RESISTOR 1231-047022000
R4 CD1221562062020 C RESISTOR 1221-562062020
R5 CD1221101062020 C RESISTOR 1221-101062020
R6 CD1221102062020 C RESISTOR 1221-102062020
R7 CD1221101062020 C RESISTOR 1221-101062020
R8 CD1221101062020 C RESISTOR 1221-101062020
R9 CD1221000062020 C RESISTOR 1221-000062020
R11 CD1221000062020 C RESISTOR 1221-000062020
R100 CD1221000062020 C RESISTOR 1221-000062020
R101 CD1221000062020 C RESISTOR 1221-000062020
R103 CD1221510061020 C RESISTOR 1221-510061020
 Symbol No. Part No. Part Name Description Local
