3-8
SMPS board
Block No. [0][2]
R317 CD1221102062020 C RESISTOR 1221-102062020
R318 CD1221102062020 C RESISTOR 1221-102062020
R320 CD1221223062020 C RESISTOR 1221-223062020
R321 CD1221472062020 C RESISTOR 1221-472062020
R322 CD1221223062020 C RESISTOR 1221-223062020
R323 CD1221102062020 C RESISTOR 1221-102062020
R324 CD1221103062020 C RESISTOR 1221-103062020
R325 CD1221473062020 C RESISTOR 1221-473062020
R326 CD1221103062020 C RESISTOR 1221-103062020
R327 CD1221472062020 C RESISTOR 1221-472062020
R328 CD1221473062020 C RESISTOR 1221-473062020
R329 CD1221105062020 C RESISTOR 1221-105062020
R330 CD1221102062020 C RESISTOR 1221-102062020
R331 CD1221220062020 C RESISTOR 1221-220062020
R332 CD1221220062020 C RESISTOR 1221-220062020
R333 CD1221220062020 C RESISTOR 1221-220062020
R334 CD1221220062020 C RESISTOR 1221-220062020
R335 CD1221220062020 C RESISTOR 1221-220062020
R336 CD1221102062020 C RESISTOR 1221-102062020
R337 CD1221102062020 C RESISTOR 1221-102062020
R338 CD1221000062020 C RESISTOR 1221-000062020
R339 CD1221000062020 C RESISTOR 1221-000062020
R355 CD1221000062020 C RESISTOR 1221-000062020
R356 CD1221000062020 C RESISTOR 1221-000062020
R358 CD1231121012000 RESISTOR 1231-121012000
R359 CD1221223062020 C RESISTOR 1221-223062020
R360 CD1221472062020 C RESISTOR 1221-472062020
R361 CD1221472062020 C RESISTOR 1221-472062020
R362 CD1221103062020 C RESISTOR 1221-103062020
R363 CD1221102062020 C RESISTOR 1221-102062020
R364 CD1221102062020 C RESISTOR 1221-102062020
R365 CD1221102062020 C RESISTOR 1221-102062020
R366 CD1221103062020 C RESISTOR 1221-103062020
R367 CD1221102062020 C RESISTOR 1221-102062020
R368 CD1221103062020 C RESISTOR 1221-103062020
R369 CD1221103062020 C RESISTOR 1221-103062020
R370 CD1221223062020 C RESISTOR 1221-223062020
R373 CD1221102062020 C RESISTOR 1221-102062020
R374 CD1221102062020 C RESISTOR 1221-102062020
R375 CD1221103062020 C RESISTOR 1221-103062020
R376 CD1221102062020 C RESISTOR 1221-102062020
R377 CD1221102062020 C RESISTOR 1221-102062020
R378 CD1221102062020 C RESISTOR 1221-102062020
R379 CD1221102062020 C RESISTOR 1221-102062020
R380 CD1221103062020 C RESISTOR 1221-103062020
R381 CD1221102062020 C RESISTOR 1221-102062020
R382 CD1221102062020 C RESISTOR 1221-102062020
R383 CD1221000062020 C RESISTOR 1221-000062020
R384 CD1221103062020 C RESISTOR 1221-103062020
R385 CD1221103062020 C RESISTOR 1221-103062020
R387 CD1221103062020 C RESISTOR 1221-103062020
R388 CD1221103062020 C RESISTOR 1221-103062020
R389 CD1221392062020 C RESISTOR 1221-392062020
R390 CD1221392062020 C RESISTOR 1221-392062020
R391 CD1221103062020 C RESISTOR 1221-103062020
R392 CD1221223062020 C RESISTOR 1221-223062020
R393 CD1221123062020 C RESISTOR 1221-123062020
R394 CD1221682062020 C RESISTOR 1221-682062020
R395 CD1221472062020 C RESISTOR 1221-472062020
R396 CD1221103062020 C RESISTOR 1221-103062020
R401 CD1221223062020 C RESISTOR 1221-223062020
R402 CD1221223062020 C RESISTOR 1221-223062020
R403 CD1221513062020 C RESISTOR 1221-513062020
R404 CD1221513062020 C RESISTOR 1221-513062020
R405 CD1221222062020 C RESISTOR 1221-222062020
R406 CD1221222062020 C RESISTOR 1221-222062020
R407 CD1221333062020 C RESISTOR 1221-333062020
R408 CD1221333062020 C RESISTOR 1221-333062020
R409 CD1221220062020 C RESISTOR 1221-220062020
R410 CD1221105062020 C RESISTOR 1221-105062020
R411 CD1221105062020 C RESISTOR 1221-105062020
R412 CD1221105062020 C RESISTOR 1221-105062020
R413 CD1221393062020 C RESISTOR 1221-393062020 A,B,C,
F,G,H
R413 CD1221473062020 C RESISTOR 1221-473062020 D,E,I,J,
K,L,M
R414 CD1221105062020 C RESISTOR 1221-105062020
R415 CD1221000062020 C RESISTOR 1221-000062020
 Symbol No. Part No. Part Name Description Local
R416 CD1221000062020 C RESISTOR 1221-000062020
R417 CD1221220062020 C RESISTOR 1221-220062020
R418 CD1221220062020 C RESISTOR 1221-220062020
R419 CD1221102062020 C RESISTOR 1221-102062020 D,E,I,J,
K,L,M
R424 CD1221000062020 C RESISTOR 1221-000062020 D,E,I,J,
K,L,M
R425 CD1221000062020 C RESISTOR 1221-000062020 D,E,I,J,
K,L,M
R430 CD1221471062020 C RESISTOR 1221-471062020
R431 CD1221102062020 C RESISTOR 1221-102062020
R433 CD1221000062020 C RESISTOR 1221-000062020
R434 CD1221220062020 C RESISTOR 1221-220062020
R435 CD1221104062020 C RESISTOR 1221-104062020
R436 CD1221332062020 C RESISTOR 1221-332062020
R437 CD1221101062020 C RESISTOR 1221-101062020
R443 CD1221000062020 C RESISTOR 1221-000062020
R445 CD1221103062020 C RESISTOR 1221-103062020
R446 CD1221103062020 C RESISTOR 1221-103062020
L1 CD2105000000100 EMI FILTER BEAD 2105-000000100
L2 CD1608300025000 TOROIDAL COIL 1608-300025000
L3 CD1608300025000 TOROIDAL COIL 1608-300025000
L205 CD1614330010000 COIL 1614-330010000
L206 CD1614330010000 COIL 1614-330010000
L207 CD1614330010000 COIL 1614-330010000
L208 CD1614330010000 COIL 1614-330010000
L211 CD1604101350000 COIL 1604-101350000
L212 CD1604101350000 COIL 1604-101350000
L213 CD1604101350000 COIL 1604-101350000
CN201 CD3106121021000 FFC CONNECTOR 3106-121021000
CN202 CD3106101621020 FFC CONNECTOR 3106-101621020
CN203 CD3505090252000 CONNECTOR WIRE 3505-090252000
CN204 CD3101200821010 HEADER 3101-200821010
CN207 CD3106122021000 FFC CONNECTOR 3106-122021000
CN208 CD3101200321010 HEADER 3101-200321010
CN210 CD3101200721000 HEADER 3101-200721000
CN211 CD3505040252500 CONNECTOR WIRE 3505-040252500
CN212 CD3401000000310 SP TERMINAL 3401-000000310
EC1 CD1132106053060 E CAPACITOR 1132-106053060
FB03 CD1221000062030 C RESISTOR 1221-000062030
FB04 CD1221000062030 C RESISTOR 1221-000062030
FB07 CD1221000062030 C RESISTOR 1221-000062030
FB09 CD1221000062030 C RESISTOR 1221-000062030
FB10 CD1221000062030 C RESISTOR 1221-000062030
X203 CD1001000327130 CRYSTAL 1001-000327130
Z201 CD1313055510000 Z DIODE 1313-055510000
Z214 CD1313055910000 Z DIODE 1313-055910000
Z215 CD1313055330010 Z DIODE 1313-055330010
Z216 CD1313055330010 Z DIODE 1313-055330010
Z218 CD1313055560020 Z DIODE 1313-055560020
ZD1 CD1323001110000 Z DIODE 1323-001110000
 Symbol No. Part No. Part Name Description Local
U1 CD1512001216020 IC 1512-001216020
U2 CD1415008170000 PHOTO COUPLER 1415-008170000
U3 CD1512000431020 IC 1512-000431020
U6 CD1512000431020 IC 1512-000431020
D1 CD1311002070020 DIODE 1311-002070020
D2 CD1311002070020 DIODE 1311-002070020
D3 CD1311002070020 DIODE 1311-002070020
D4 CD1311002070020 DIODE 1311-002070020
D5 CD1311140070020 DIODE 1311-140070020
D6 CD1311001070050 DIODE 1311-001070050
D7 CD1321041480050 DIODE 1321-041480050
D8 CD1311001040030 DIODE 1311-001040030 A,B,C,
D,E,F,
G,H , J,
L,M
 Symbol No. Part No. Part Name Description Local
