3-9
Power board
Block No. [0][2]
T101 OW08-82059-80 COIL AHK7-8646
T102 OW08-82057-80 COIL AHK7-8651
T103 OW08-82059-80 COIL AHK7-8646
T104 OW08-94615-80 COIL OHK7-862
T105 OW08-86583-90 COIL KHI7-865
T106 OW08-72038-80 COIL Coil 7MC/A084X
ACIN1 OW37-00020-80 EYELET D=2X4mm
ACIN2 OW37-00020-80 EYELET D=2X4mm
ANT1 OW29-00300-00 FM ANT Pig Tail
ANT2 OW29-00300-01 FM ANT Wire
CF101 OW09-50107-84 CER FILTER LT10.7MS3 A10
CF102 OW09-50107-84 CER FILTER LT10.7MS3 A10
CN102 OW20-12020-81 CONNECTOR 2P
CN103 OW20-11090-80 CONNECTOR 9P
CN202 OW20-41092-57 CONNECTOR WIRE 9P
CN203 OW20-11090-80 CONNECTOR 9P
CN301 OW20-12030-80 CONNECTOR 3P
CN303 OW20-11080-80 CONNECTOR 8P
CN401 OW20-11040-80 CONNECTOR 4P
CN402 OW20-12100-80 CONNECTOR 10P
CN403 OW20-12020-80 CONNECTOR 2P
CN801 OW12-00006-80 SPK.TERMINAL SPK.Terminal
FMANT OW25-04300-80 CONNECT BM V1P
J101 OW07-75000-06F C RESISTOR 0 1/16W
J102 OW07-75000-06F C RESISTOR 0 1/16W
J201 OW07-75000-06F C RESISTOR 0 1/16W
J205 OW07-75001-05F C RESISTOR 0 1/8W
J370 OW07-75001-05F C RESISTOR 0 1/8W
J371 OW07-75001-05F C RESISTOR 0 1/8W
J372 OW07-75001-05F C RESISTOR 0 1/8W
J373 OW07-75001-05F C RESISTOR 0 1/8W
J374 OW07-75000-06F C RESISTOR 0 1/16W
J375 OW07-75001-05F C RESISTOR 0 1/8W
J380 OW07-75000-06F C RESISTOR 0 1/16W
J381 OW07-75000-06F C RESISTOR 0 1/16W
J382 OW07-75000-06F C RESISTOR 0 1/16W
JK101 OW00-00004-32 DAB MODULEFS
JK101 OW25-00044-81 CONNECTOR 44P
JK103 OW12-00007-92 ANTENNA SOCKET F-TYPE
JK301 OW12-21315-01 AUX JACK CKX3.5-02-5P
JK401 OW12-21315-00 PHONE JACK CKS3.5-02J5P2K
X101 OW04-00075-81 CRYSTAL 75kHz
XXXXX OW20-61031-21 FFC WIRE
3Pin AUX PCB
CON301
XXXXX OW37-00020-80 EYELET
D=2X4mm
ACOUT1
XXXXX OW37-00020-80 EYELET
D=2X4mm
ACOUT2
XXXXX OW20-61063-80 FFC WIRE
6P CN201
toCassHead
XXXXX OW20-11030-80 CONNECTOR 3P CON302
XXXXX OW25-23050-82 WIRE
2P CON505 to
CON504
XXXXX OW20-12040-80 CONNECTOR 4P CON801
XXXXX OW20-61022-60 FFC WIRE
30X1C P=2
L=280mm
XXXXX OW08-04344-20 FERRITE CORE For FM ANT
XXXXX OW08-04344-50 FERRITE CORE For CassAudio
XXXXX OW84-00004-82 ROUND WIRE For CassHeadWire
XXXXX OW39-09025-84 HEAT SINK For Q433
XXXXX OW39-07635-88G HEAT SINK For IC102
XXXXX OW39-07635-88G HEAT SINK For IC103
XXXXX OW39-09025-84 HEAT SINK For IC402
XXXXX MT-424UY LED Amber LED501
XXXXX MT-424UY LED Amber LED502
XXXXX OW20-11020-80 CONNECTOR
2P ON DAB
Module
XXXXX OW20-42041-82 FFC WIRE 4P CON401
XXXXX OW11-00004-20 MAIN PCB
XXXXX OW08-04344-14 FERRITE CORE T16X12X8mm(x3)
 Z402 9.1V 0.5W Z DIODE OW02-50091-81
 Z441 6.2V 0.5W Z DIODE OW02-50062-80
 ZD101 5.6V 0.5W Z DIODE OW02-50056-80
 ZD107 5.6V 0.5W Z DIODE OW02-50056-80
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
 IC801 LA4628 IC OW03-04628-00
 IC901 RS602 IC OW02-00602-80
Q801 8050D TRANSISTOR OW01-08050-81
Q802 8050D TRANSISTOR OW01-08050-81
D801 1N4148 DIODE OW02-04148-81
D803 1N4148 DIODE OW02-04148-81
 D901 1N4001 DIODE OW02-04001-81
 D902 1N4001 DIODE OW02-04001-81
 D903 1N4001 DIODE OW02-04001-81
 D904 1N4001 DIODE OW02-04001-81
C801 OW06-72106-20 E CAPACITOR 10uF 25V
C802 OW06-75225-20 E CAPACITOR 2.2uF 50V
C803 OW06-75225-20 E CAPACITOR 2.2uF 50V
C805 OW06-71107-20 E CAPACITOR 100uF 16V
C806 OW06-72106-20 E CAPACITOR 10uF 25V
C807 OW05-70101-05 C CAPACITOR 100pF 50V
C808 OW06-75474-20 E CAPACITOR 0.47uF 50V
C809 OW05-72104-10 M CAPACITOR 0.1uF 50V
C810 OW05-72104-10 M CAPACITOR 0.1uF 50V
C811 OW05-72104-10 M CAPACITOR 0.1uF 50V
C812 OW05-72104-10 M CAPACITOR 0.1uF 50V
 C813 OW06-72478-81 E CAPACITOR 4700uF 25V
C821 OW05-70101-05 C CAPACITOR 100pF 50V
C822 OW05-70101-05 C CAPACITOR 100pF 50V
 C901 OW06-71338-81 E CAPACITOR 3300uF 16V
C902 OW05-70223-10 C CAPACITOR 0.022uF 50V
C903 OW05-70223-10 C CAPACITOR 0.022uF 50V
C904 OW05-70223-10 C CAPACITOR 0.022uF 50V
C905 OW05-70223-10 C CAPACITOR 0.022uF 50V
C906 OW05-77104-82 C CAPACITOR 0.1uF
 C907 OW06-72228-21 E CAPACITOR 2200uF 25V
 C908 OW05-77104-82 C CAPACITOR 0.1uF
 C909 OW05-77104-82 C CAPACITOR 0.1uF
 C910 OW05-77104-82 C CAPACITOR 0.1uF
 C911 OW05-77104-82 C CAPACITOR 0.1uF
C912 OW05-77104-82 C CAPACITOR 0.1uF
R801 OW07-74153-50T C RESISTOR 15K 1/8W
R802 OW07-74223-50T C RESISTOR 22K 1/8W
R803 OW07-74102-50T C RESISTOR 1K 1/8W
R804 OW07-74103-50T C RESISTOR 10K 1/8W
R805 OW07-74103-50T C RESISTOR 10K 1/8W
R806 OW07-74102-50T C RESISTOR 1K 1/8W
R810 OW07-74562-50T C RESISTOR 5.6K 1/8W
R812 OW07-74022-00T C RESISTOR 2.2 1/4W
R813 OW07-74022-00T C RESISTOR 2.2 1/4W
R814 OW07-74022-00T C RESISTOR 2.2 1/4W
R815 OW07-74022-00T C RESISTOR 2.2 1/4W
R821 OW07-74822-50T C RESISTOR 8.2K 1/8W
R822 OW07-74822-50T C RESISTOR 8.2K 1/8W
BRN-A OW37-00020-80 EYELET D=2X4mm
BRN-B OW37-00020-80 EYELET D=2X4mm
CN801 OW20-61010-80 FFC WIRE 10P
CN802 OW20-42041-81 CONECTOR WIRE 4P
 F901 OW33-57162-03W FUSE 250V
 F902 OW33-57632-03W FUSE 250V
ORG-A OW37-00020-80 EYELET D=2 X 4mm
ORG-B OW37-00020-80 EYELET D=2 X 4mm
XXXXX OW08-04344-53 FERRITE CORE
25X15X10 For
ACCord
XXXXX OW08-04344-53 FERRITE CORE For CN802 Wire
XXXXX OW39-10001-81 FUSE HOLDER For F901(x2)
XXXXX OW39-10001-81 FUSE HOLDER For F902(x2)
XXXXX OW39-00882-80 HEAT SINK For IC901
XXXXX OW11-80300-01 POWER PCB H300
