3-4
General assembly
Block No. [M][1][M][M]
Symbol No.
Part No. Part Name Description Local
1 GV10123-003A FRONT PANEL
2 GV40077-002A JVC BADGE
3 GV40367-001A REMOTE LENS
4 GV40366-001A STANDBY LENS
5 GV30398-003A FUNC.BTN.ASSY.
6 GV20196-003A CONTROL BTN.
7 GV20195-003A FRONT PLATE
8 GV30390-003A FRONT LENS A
9 GV30391-002A FRONT LENS B
10 GV30389-003A VOLUME ORNAMENT
11 GV30393-002A LCD COVER
12 QSW0920-001 PUCH LOCK SW
13 WJM0249-001A E-SI C WIRE C-F
14 QYSDSF2608Z SCREW 2.6mm x 8mm
15 QYSDSF2608Z SCREW 2.6mm x 8mm
16 QYSDSF2608Z SCREW 2.6mm x 8mm(x3)
17 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
18 QYSDSF2608Z SCREW 2.6mm x 8mm
19 QYSDSF2608Z SCREW 2.6mm x 8mm(x4)
20 QYSDSF2608Z SCREW 2.6mm x 8mm(x2)
21 GV40412-001A OPAQUE SHEET A
22 GV40413-001A OPAQUE SHEET B
23 GV40416-001A MIRROR SHEET
24 GV40416-002A MIRROR SHEET
25 GV10124-005A CASSETTE DOOR
26 GV40277-001A DOOR SPRING
27 VKY4180-401 CASSETTE SPRING (x2)
28 GV40034-001A DAMPER ASSY.
29 GV40369-001A SPRING HOLDER
30 QYSBSF3012Z TAP SCREW 3.0mm x 12mm(x4)
31 GV30124-002A TRANS SHIELD
32 GV40170-003A SPACER
33 GV40414-001A EJECT SAFETY
34 VKW5258-003 TORSION SPRING
35 E406293-001 SPECIAL SCREW
36 GV40196-001A INSULATOR (x2)
37 GV40196-002A INSULATOR (x2)
38 KSM-213CCMJ CD MECHA ASSY
39 GV10102-002A CLAMPER BASE
40 VYH7313-005 P.C.MAGNET
41 E306836-223SS CD YOKE (JES)
42 VYH1240-001 TRAY
43 GV30202-001A CD CLAMPER
44 QYSBSF3008Z SCREW 3mm x 8mm(x4)
45 QYSBSF3008Z SCREW 3mm x 8mm
46 QYSBSF3008Z SCREW 3mm x 8mm(x2)
47 QYSDSF2608Z SCREW 2.6mm x 8mm
48 GV40122-003A FOOT SPACER
49 GV30220-001A SHIELD CASE(UPP
50 GV30221-001A SHIELD CASE(LOW
51 QYSBST3004Z SCREW 3mm x 4mm(x4)
53 VYSA1R3-003 SPACER (x3)
54 GV10103-002A BOTTOM CHASSIS
55 GV40312-002A FOOT SPACER (x4)
56 GV30395-002A HEAT SINK
57 QYSBSF3016Z TAP SCREW 3mm x 16mm(x2)
58 QYSBSF3016Z TAP SCREW 3mm x 16mm(x2)
59 QYSBSF3016Z TAP SCREW 3mm x 16mm(x2)
60 QYSBST4006Z SCREW 4mm x 6mm(x4)
61 QYSSST3008Z SCREW 3mm x 8mm(x2)
62 QMPK200-200-JD POWER CORD(EU) 2m BLACK
63 QZW0033-001 STRAIN RELIEF
64 GV30414-001A IC HOLDER
65 GV40322-001A PROTECT SHEET A
66 GV40170-003A SPACER
67 GV30349-011A SPACER
68 QYSBSF3008Z SCREW 3mm x 8mm
69 GV10104-013A REAR PANEL
70 GV10105-012A REAR COVER
71 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
72 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
73 QYSBSGY3010E SPECIAL SCREW 3mm x 10mm(x2)
74 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
75 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
76 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
77 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
78 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
79 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm
80 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x2)
81 QYSBSF3012E SPECIAL SCREW 3mm x 12mm(x2)
82 GV30493-001A FAN BRACKET
83 QAR0230-001 FAN
84 GV10106-001A/S/ METAL COVER
85 QYSDSG3006M TAP SCREW 3mm x 6mm(x2)
86 QYSBSGY3008E SPECIAL SCREW 3mm x 8mm(x6)
87 GV30397-005A CD FITTING
88 GV30396-001A VOL.KNOB
89 GV30492-001A RATING LABEL
90 LV41843-001A LASER CAUTION
91 GV40168-008A SHEET
92 GV40285-001A MIC VOL.KNOB
93 GV30273-001A MIC COVER
94 GV40286-001A MIC BRACKET
95 QYSDSG3006M TAP SCREW 3mm x 6mm(x2)
96 QUQH12-0914AJ CARD WIRE FC 33
97 QUQH12-1018AJ CARD WIRE FC 34
98 QUQH12-0507BJ CARD WIRE FC606
99 QUQH10-1914BJ CARD WIRE
100 QUQH10-1507AJ CARD WIRE
101 WJU0008-001A CARD WIRE
102 QUQH12-0932BJ CARD WIRE FC 1
103 QUQH12-1922AJ CARD WIRE FC731
104 QUQH12-2317AJ CARD WIRE FC730
105 QUQH12-1316AJ CARD WIRE FC760
106 QUQH10-0910BJ CARD WIRE FC750
107 QUQ110-1609AJ CARD WIRE FC601
108 QJJ010-060801 WIRE W 801
109 QMF51W2-3R15-J8 FUSE F 1000 3.15A AC250V
110 QMF51W2-2R0-J8 FUSE F 1001 2A AC250V
111 QMF51W2-1R6-J8 FUSE F 1002 1.6A AC250V
112 QMF51W2-5R0-J8 FUSE F 1003 5A AC250V
113 QMF51W2-5R0-J8 FUSE F 1004 5A AC250V
114 QQT0406-003 POWER TRANSF T 1000
115 GV30392-003A LCD HOLDER
116 GV40368-001A LCD LENS
117 GV40411-001A LED HOLDER (x3)
118 LV40057-H30B HEAT SINK
119 QYSBSF3010Z TAP SCREW 3mm x 10mm
Symbol No.
Part No. Part Name Description Local
To Next Page
