3-16
VCD board
Block No. [0][5][0][0]
C34 NCB21HK-223X C CAPACITOR 0.022uF 50V K
C35 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C36 EEKC1HM-105ZJC E CAPACITOR
C37 EEKC1HM-105ZJC E CAPACITOR
C38 EETC1HM-224ZJC E CAPACITOR
C39 EETC1HM-105ZJC E CAPACITOR
C40 QETN1CM-106Z E CAPACITOR 10uF 16V M
C41 QETN1CM-106Z E CAPACITOR 10uF 16V M
C42 NCB21HK-152X C CAPACITOR 1500pF 50V K
C43 NCB21HK-152X C CAPACITOR 1500pF 50V K
C44 QETN1CM-106Z E CAPACITOR 10uF 16V M
C45 QETN1CM-106Z E CAPACITOR 10uF 16V M
C46 NCB21HK-273X C CAPACITOR 0.027uF 50V K
C47 EETC1HM-105ZJC E CAPACITOR
C48 NCB21HK-222X C CAPACITOR 2200pF 50V K
C49 NCS21HJ-471X C CAPACITOR 470pF 50V J
C50 EEKC1CM-226ZJC E CAPACITOR
C51 EEKC1HM-105ZJC E CAPACITOR
C52 QFVJ1HJ-274Z MF CAPACITOR 0.27uF 50V J
C53 EETC1CM-226ZJC E CAPACITOR
C54 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C57 NCB21HK-102X C CAPACITOR 1000pF 50V K
C58 NCB21HK-473X C CAPACITOR 0.047uF 50V K
C59 NCB21HK-102X C CAPACITOR 1000pF 50V K
R1 QRE141J-560Y C RESISTOR 56
Ω
1/4W J
R2 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R3 NRSA02J-224X MG RESISTOR 220k
Ω
1/10W J
R4 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R5 NRSA02J-560X MG RESISTOR 56
Ω
1/10W J
R6 NRSA02J-240X MG RESISTOR 24
Ω
1/10W J
R10 NRSA02J-222X MG RESISTOR 2.2k
Ω
1/10W J
R13 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R14 NRSA02J-104X MG RESISTOR 100k
Ω
1/10W J
R15 NRSA02J-332X MG RESISTOR 3.3k
Ω
1/10W J
R16 NRSA02J-472X MG RESISTOR 4.7k
Ω
1/10W J
R17 QRZ9005-680X F RESISTOR 68
Ω
R18 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
R19 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
R20 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
R21 NRSA02J-562X MG RESISTOR 5.6k
Ω
1/10W J
R22 NRSA02J-472X MG RESISTOR 4.7k
Ω
1/10W J
R23 NRSA02J-182X MG RESISTOR 1.8k
Ω
1/10W J
R24 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R25 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R26 NRSA02J-222X MG RESISTOR 2.2k
Ω
1/10W J
R27 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R28 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R29 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R30 NRSA02J-122X MG RESISTOR 1.2k
Ω
1/10W J
R31 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
R32 NRSA02J-102X MG RESISTOR 1k
Ω
1/10W J
R33 NRSA02J-331X MG RESISTOR 330
Ω
1/10W J
R34 NRSA02J-470X MG RESISTOR 47
Ω
1/10W J
R35 NRSA02J-562X MG RESISTOR 5.6k
Ω
1/10W J
R36 NRSA02J-332X MG RESISTOR 3.3k
Ω
1/10W J
R37 NRSA02J-103X MG RESISTOR 10k
Ω
1/10W J
R38 NRSA02J-563X MG RESISTOR 56k
Ω
1/10W J
R39 NRSA02J-563X MG RESISTOR 56k
Ω
1/10W J
R40 NRSA02J-243X MG RESISTOR 24k
Ω
1/10W J
R41 NRSA02J-332X MG RESISTOR 3.3k
Ω
1/10W J
R60 NRSA02J-0R0X MG RESISTOR 0
Ω
1/10W J
L1 QQR0796-003 COIL BLOCK
T1 QQR0793-001 IFT
CF1 QAX0677-001Z C FILTER 10.700MHz
CF2 QAX0677-001Z C FILTER 10.700MHz
CF3 QAX0610-001Z C DISCRIMINATOR 10.700MHz
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
J1 QNB0014-001 ANT.TERMINAL
TU1 QAU0161-001 FRONT END
X1 QAX0402-001 CRYSTAL 75.0kHz
Symbol No.
Part No. Part Name Description Local
Symbol No.
Part No. Part Name Description Local
IC101 ES3880FM IC
IC102 AT27C020-70JCU4 IC
IC103 GLT44016-35J4-X IC (4M DRAM) 4M DRAM
IC103 M11B416256A-30J DRAM IC
IC103 M11B416256A-35J DRAM IC
IC104 ES3883F IC
IC105 RT9161/A-27CG-X IC
IC106 TC7S08F-W IC
IC107 TC7W08FU-X IC
C101 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C102 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C103 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C104 QERF1CM-106Z E CAPACITOR 10uF 16V M
C105 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C106 QERF1CM-106Z E CAPACITOR 10uF 16V M
C107 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C109 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C110 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C111 NCS31HJ-471X C CAPACITOR 470pF 50V J
C112 NCS31HJ-471X C CAPACITOR 470pF 50V J
C113 NCS31HJ-220X C CAPACITOR 22pF 50V J
C114 NCB31HK-102X C CAPACITOR 1000pF 50V K
C115 NCS31HJ-220X C CAPACITOR 22pF 50V J
C116 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C117 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C118 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C120 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C121 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C122 QERF1AM-107Z E CAPACITOR 100uF 10V M
C123 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C124 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C125 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C126 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C127 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C128 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C129 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C130 QERF1AM-107Z E CAPACITOR 100uF 10V M
C131 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C132 QERF1AM-107Z E CAPACITOR 100uF 10V M
C133 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C134 QERF1CM-106Z E CAPACITOR 10uF 16V M
C135 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C136 NCF31CZ-104X C CAPACITOR 0.1uF 16V Z
C137 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C138 QERF1AM-107Z E CAPACITOR 100uF 10V M
C140 NCS31HJ-220X C CAPACITOR 22pF 50V J
C141 NCS31HJ-220X C CAPACITOR 22pF 50V J
R101 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R102 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R103 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R104 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R105 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R106 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R107 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R108 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R109 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R111 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R112 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R113 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R119 NRSA63J-0R0X MG RESISTOR 0
Ω
1/16W J
R120 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R121 NRSA63J-104X MG RESISTOR 100k
Ω
1/16W J
R128 NRSA63J-330X MG RESISTOR 33
Ω
1/16W J
R130 NRSA63J-330X MG RESISTOR 33
Ω
1/16W J
R132 NRSA63J-271X MG RESISTOR 270
Ω
1/16W J
R133 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R134 NRSA63J-750X MG RESISTOR 75
Ω
1/16W J
R135 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R136 NRSA63J-100X MG RESISTOR 10
Ω
1/16W J
R137 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R138 NRSA63J-472X MG RESISTOR 4.7k
Ω
1/16W J
R139 NRSA63J-330X MG RESISTOR 33
Ω
1/16W J
To Next Page
