JVC UX-J55V User Manual

3-17
Cassette switch board
Block No. [0][6][0][0]
Head amplifier board
Block No. [0][7][0][0]
R140 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R142 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R145 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R146 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R147 NRSA63J-221X MG RESISTOR 220 Ω 1/16W J
R148 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
L101 NQL591K-3R3X INDUCTOR C.M. 3.3uH K
L102 NQL591K-3R3X INDUCTOR C.M. 3.3uH K
CN101 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
CN102 QGF1036F1-15 CONNECTOR FFC/FPC (1-15)
K101 NRSA02J-100X MG RESISTOR 10
Ω 1/10W J
K102 NCB21HK-103X C CAPACITOR 0.01uF 50V K
K103 NRSA02J-180X MG RESISTOR 18 Ω 1/10W J
K104 NRSA02J-102X MG RESISTOR 1k Ω 1/10W J
X101 QAX0700-001Z CRYSTAL 27.000000MHz
 Symbol No. Part No. Part Name Description Local
IC1 SG-105F3-BB,C PHOTO SENSER
D1 1SR139-400-T2 SI DIODE
R371 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
VR37 QVP0077-103Z TRIM RESISTOR 10k Ω
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
FW100 QUM024-07A2Z3 PARA RIBON WIRE
P1 QNZ0104-001 POST PIN
SW1 QSW0832-001 CASS.SWITCH
SW2 QSW0832-001 CASS.SWITCH
SW5 QSW0832-001 CASS.SWITCH
SW6 QSW0859-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC32 HA12238F IC
IC33 CD4094BC IC
Q302 2SC2001/K/-T TRANSISTOR
Q305 2SC2001/K/-T TRANSISTOR
Q342 KRA111M-T DIGI TRANSISTOR
Q343 2SC3576-JVC-T TRANSISTOR
Q344 2SC3576-JVC-T TRANSISTOR
Q345 2SC3576-JVC-T TRANSISTOR
Q346 2SC3576-JVC-T TRANSISTOR
Q347 KRC107M-T DIGI TRANSISTOR
Q371 KTA1271/OY/-T TRANSISTOR
Q372 KRC107M-T DIGI TRANSISTOR
Q375 2SB562/C/-T TRANSISTOR
Q376 KTC3199/GL/-T TRANSISTOR
D340 MTZJ5.1B-T2 Z DIODE
D375 MTZJ5.1B-T2 Z DIODE
C101 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C102 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C103 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C104 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C105 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C106 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C107 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C109 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
 Symbol No. Part No. Part Name Description Local
C110 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C113 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C120 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C121 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C201 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C202 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C203 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C204 QCBB1HK-221Y C CAPACITOR 220pF 50V K
C205 QCBB1HK-391Y C CAPACITOR 390pF 50V K
C206 QERF1HM-225Z E CAPACITOR 2.2uF 50V M
C207 QCBB1HK-271Y C CAPACITOR 270pF 50V K
C209 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C210 QDYB1CM-682Y C CAPACITOR 6800pF 16V M
C213 QFLA1HJ-104Z M CAPACITOR 0.1uF 50V J
C220 QCSB1HK-4R7Y C CAPACITOR 4.7pF 50V K
C221 QCBB1HK-331Y C CAPACITOR 330pF 50V K
C300 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C301 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C304 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C306 FQETJ1AM-227Z E CAPACITOR
C307 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C308 QDXB1CM-152Y C CAPACITOR 1500pF 16V M
C310 QCBB1HK-223Y C CAPACITOR 0.022uF 50V K
C313 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C314 QCFB1HZ-105Y C CAPACITOR 1uF 50V Z
C316 QFG32AJ-223Z PP CAPACITOR 0.022uF 100V J
C319 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
C331 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C340 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C341 QEKJ1HM-105Z E CAPACITOR 1uF 50V M
C342 QEKJ1CM-476Z E CAPACITOR 47uF 16V M
C371 QEKJ1EM-475Z E CAPACITOR 4.7uF 25V M
C374 QEKJ1AM-107Z E CAPACITOR 100uF 10V M
C376 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
R101 QRE141J-512Y C RESISTOR 5.1k Ω 1/4W J
R102 QRE141J-512Y C RESISTOR 5.1k Ω 1/4W J
R104 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R105 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R106 QRE141J-113Y C RESISTOR 11k Ω 1/4W J
R107 QRE141J-912Y C RESISTOR 9.1k Ω 1/4W J
R108 QRE141J-273Y C RESISTOR 27k Ω 1/4W J
R110 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
R116 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R121 QRE141J-153Y C RESISTOR 15k Ω 1/4W J
R201 QRE141J-512Y C RESISTOR 5.1k Ω 1/4W J
R202 QRE141J-512Y C RESISTOR 5.1k Ω 1/4W J
R204 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R205 QRE141J-104Y C RESISTOR 100k Ω 1/4W J
R206 QRE141J-113Y C RESISTOR 11k
Ω 1/4W J
R207 QRE141J-912Y C RESISTOR 9.1k Ω 1/4W J
R208 QRE141J-273Y C RESISTOR 27k
Ω 1/4W J
R210 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R216 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R221 QRE141J-153Y C RESISTOR 15k
Ω 1/4W J
R301 QRE141J-221Y C RESISTOR 220
Ω 1/4W J
R302 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R303 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
 R304 QRJ146J-101X UNF C RESISTOR 100 Ω 1/4W J
R305 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R306 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
 R310 QRJ146J-4R7X UNF C RESISTOR 4.7 Ω 1/4W J
R313 QRE141J-2R2Y C RESISTOR 2.2
Ω 1/4W J
R314 QRE141J-153Y C RESISTOR 15k
Ω 1/4W J
R315 QRE141J-101Y C RESISTOR 100 Ω 1/4W J
R327 QRE141J-474Y C RESISTOR 470k
Ω 1/4W J
R335 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R336 QRE141J-223Y C RESISTOR 22k
Ω 1/4W J
R337 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R338 QRE141J-392Y C RESISTOR 3.9k Ω 1/4W J
R339 QRE141J-104Y C RESISTOR 100k
Ω 1/4W J
R340 QRE141J-681Y C RESISTOR 680
Ω 1/4W J
R341 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
R342 QRE141J-243Y C RESISTOR 24k
Ω 1/4W J
R343 QRE141J-183Y C RESISTOR 18k
Ω 1/4W J
R344 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R345 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R346 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
