JVC UX-P400 Service Manual

3-13
Power board
Block No. [0][2][0][0]
CN271 QGA2501C1-05 CONNECTOR W-B (1-5)
CN700 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN701 QGF1205F1-10 CONNECTOR FFC/FPC (1-10)
CN702 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
CN711 QGA2501C1-02 CONNECTOR W-B (1-2)
CN730 QGF1205C1-15 CONNECTOR FFC/FPC (1-15)
J200 QNN0420-001 SURROUND JACK
J271 QNS0170-001 HEADPHONE JACK
J280 QNB0038-001 SPK.TERMINAL
K2070 QQR0621-001Z COIL
K2170 QQR0621-001Z COIL
K2503 NQR0339-001X FERRITE BEADS
K7001 QQR0621-001Z COIL
K7300 QQR0621-001Z COIL
PP9 QZW0038-001 WIRE CLAMP
S2200 GV30349-006A SPACER
S2202 GV30349-006A SPACER
X7001 QAX0718-001Z CRYSTAL 8.000000MHz
 Symbol No. Part No. Part Name Description Local
 IC411 LA4628 IC
IC750 NJU6433FG1 LCD DRIVER
IC760 GP1UM261XK IR DETECT UNIT 38kHz
Q1001 KTC3199/GL/-T TRANSISTOR
Q1002 KTC1027/OY/-T TRANSISTOR
Q1003 2SD1266/P/ TRANSISTOR
P400
US,P4
00UT,
P400
UW
Q4121 2SC3576-JVC-T TRANSISTOR
Q4122 2SC3576-JVC-T TRANSISTOR
Q4123 KRA102M-T DIGI TRANSISTOR
Q4131 KRA109M-T DIGI TRANSISTOR
Q4132 KRA109M-T DIGI TRANSISTOR
Q4133 KRA109M-T DIGI TRANSISTOR
Q4134 KRA109M-T DIGI TRANSISTOR
 Q4135 KRC109M-T DIGI TRANSISTOR
Q7600 KRC111M-T TRANSISTOR
 D1001 1N5401-TM SI DIODE
 D1002 1N5401-TM SI DIODE
 D1003 1N5401-TM SI DIODE
 D1004 1N5401-TM SI DIODE
 D1005 6A10E2 SI DIODE
 D1006 6A10E2 SI DIODE
 D1007 6A10E2 SI DIODE
 D1008 6A10E2 SI DIODE
D1013 MTZJ6.2C-T2 Z DIODE
D1014 1N4003S-T5 SI DIODE
D1015 1SS133-T2 DIODE
D1018 MTZJ11C-T2 Z DIODE
P400
US,P4
00UT,
P400
UW
D7500 SELU1E54CM-S LED
D7601 SPR-39MVWF LED RED-GREEN
D7602 1SS133-T2 DIODE
D7603 1SS133-T2 DIODE
C1001 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1002 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1003 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1004 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1005 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1006 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1007 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1008 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C1013 QDXB1CM-472Y C CAPACITOR 4700pF 16V M
C1014 QETN0JM-477Z E CAPACITOR 470uF 6.3V M
 Symbol No. Part No. Part Name Description Local
C1015 QETM1EM-108 E CAPACITOR 1000uF 25V M
P400
UF,P4
00UP
C1015 QETN1JM-477Z E CAPACITOR 470uF 63V M
P400
US,P4
00UT,
P400
UW
 C1016 QCZ9105-472 C CAPACITOR 4700pF 250V M
C1017 QFLC1HJ-472Z M CAPACITOR 4700pF 50V J
P400
US,P4
00UT,
P400
UW
C4001 QETM1EM-478 E CAPACITOR 4700uF 25V M
C4101 QETM1EM-828 E CAPACITOR 8200uF 25V M
C4102 QETN1CM-107Z E CAPACITOR 100uF 16V M
C4103 QTE1H28-105Z E CAPACITOR 1uF 50V
C4107 QETN1AM-336Z E CAPACITOR 33uF 10V M
C4108 QTE1H28-105Z E CAPACITOR 1uF 50V
C4109 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C4110 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C4111 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4112 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4113 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4114 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C4115 QETN1EM-107Z E CAPACITOR 100uF 25V M
C4117 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C4118 QDGB1HK-102Y C CAPACITOR 1000pF 50V K
C4121 QETN1CM-107Z E CAPACITOR 100uF 16V M
C4131 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C4132 QENC1EM-106Z BP E CAPACITOR 10uF 25V M
C7500 QEKC1AM-107Z E CAPACITOR 100uF 10V M
C7505 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C7600 QCBB1HK-101Y C CAPACITOR 100pF 50V K
C7601 QERF1CM-476Z E CAPACITOR 47uF 16V M
C7602 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
C7603 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
R1001 QRE141J-332Y C RESISTOR 3.3k
Ω 1/4W J
R1002 QRE141J-821Y C RESISTOR 820 Ω 1/4W J
 R1004 QRZ9042-2R2X F RESISTOR 2.2 Ω
P400
US,P4
00UT,
P400
UW
R1005 QRE141J-103Y C RESISTOR 10k Ω 1/4W J
P400
US,P4
00UT,
P400
UW
R1006 QRE141J-822Y C RESISTOR 8.2k Ω 1/4W J
P400
US,P4
00UT,
P400
UW
R4101 QRE141J-472Y C RESISTOR 4.7k
Ω 1/4W J
R4102 QRE141J-472Y C RESISTOR 4.7k Ω 1/4W J
R4103 QRE141J-2R2Y C RESISTOR 2.2
Ω 1/4W J
R4104 QRE141J-2R2Y C RESISTOR 2.2 Ω 1/4W J
R4105 QRE141J-2R2Y C RESISTOR 2.2
Ω 1/4W J
R4106 QRE141J-2R2Y C RESISTOR 2.2
Ω 1/4W J
R4107 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R4108 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R4121 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R4122 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R4123 QRE141J-222Y C RESISTOR 2.2k
Ω 1/4W J
R4131 QRE141J-473Y C RESISTOR 47k
Ω 1/4W J
R4132 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R4133 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R4134 QRE141J-473Y C RESISTOR 47k Ω 1/4W J
R7500 QRE141J-103Y C RESISTOR 10k
Ω 1/4W J
R7501 QRE141J-134Y C RESISTOR 130k
Ω 1/4W J
R7502 QRE141J-241Y C RESISTOR 240 Ω 1/4W J
R7601 QRE141J-161Y C RESISTOR 160
Ω 1/4W J
R7602 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
R7603 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R7604 QRE141J-122Y C RESISTOR 1.2k
Ω 1/4W J
R7605 QRE141J-182Y C RESISTOR 1.8k
Ω 1/4W J
R7606 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R7607 QRE141J-272Y C RESISTOR 2.7k
Ω 1/4W J
R7609 QRE141J-102Y C RESISTOR 1k
Ω 1/4W J
 Symbol No. Part No. Part Name Description Local
