JVC UX-P400 Service Manual

3-14
CD servo board
Block No. [0][3][0][0]
R7610 QRE141J-102Y C RESISTOR 1k Ω 1/4W J
R7611 QRE141J-122Y C RESISTOR 1.2k Ω 1/4W J
R7612 QRE141J-182Y C RESISTOR 1.8k Ω 1/4W J
R7613 QRE141J-222Y C RESISTOR 2.2k Ω 1/4W J
R7614 QRE141J-272Y C RESISTOR 2.7k Ω 1/4W J
 L1001 QQR1145-001 COIL
P400
UP
 T1002 QQT0253-002 POWER TRANSF
P400
UF,P4
00UP
 T1002 QQT0370-011 POWER TRANSF
P400
US,P4
00UT,
P400
UW
 CN101 QGA7901C1-02 CONNECTOR W-B (1-2)
 CN102 QGA7901C1-02 CONNECTOR W-B (1-2)
P400
UF,P4
00UP
 CN102 QGA7901C1-03 CONNECTOR W-B (1-3)
P400
US,P4
00UT,
P400
UW
CN103 QGA3901C1-04 CONNECTOR W-B (1-4)
CN104 QGB2510J1-10 CONNECTOR B-B (1-10)
 CN105 QGA7901C1-04 CONNECTOR W-B (1-4)
P400
US,P4
00UT,
P400
UW
CN401 QGB2510K2-07 CONNECTOR B-B (1-7)
CN402 QGF1205C1-11 CONNECTOR FFC/FPC (1-11)
CN403 QGB2510K2-10 CONNECTOR B-B (1-10)
CN750 QGF1205F1-15 CONNECTOR FFC/FPC (1-15)
CN751 QGF1205F1-10 CONNECTOR FFC/FPC (1-10)
CN760 QGF1205F1-10 CONNECTOR FFC/FPC (1-10)
DI750 QLD0312-001 LCD MODULE
JS760 QSW1060-001 ROTARY SW
 RY101 QSK0124-001 RELAY
 S1001 QSW0812-001 VOLTAGE SWITCH
P400
US,P4
00UT,
P400
UW
S7600 QSW0825-001Z TACT SW
S7601 QSW0825-001Z TACT SW
S7602 QSW0825-001Z TACT SW
S7603 QSW0825-001Z TACT SW
S7604 QSW0825-001Z TACT SW
S7605 QSW0825-001Z TACT SW
S7606 QSW0825-001Z TACT SW
S7607 QSW0825-001Z TACT SW
S7608 QSW0825-001Z TACT SW
S7609 QSW0825-001Z TACT SW
S7610 QSW0825-001Z TACT SW
S7611 QSW0825-001Z TACT SW
Z1001 QNG0003-001Z FUSE CLIP
Z1002 QNG0003-001Z FUSE CLIP
Z1003 QNG0003-001Z FUSE CLIP
P400
US,P4
00UT,
P400
UW
Z1004 QNG0003-001Z FUSE CLIP
P400
US,P4
00UT,
P400
UW
Z1007 QNG0003-001Z FUSE CLIP
Z1008 QNG0003-001Z FUSE CLIP
Z1009 QNG0003-001Z FUSE CLIP
Z1010 QNG0003-001Z FUSE CLIP
 Symbol No. Part No. Part Name Description Local
 Symbol No. Part No. Part Name Description Local
IC201 BR24L08FV-W-X IC
IC251 MN101C61GNA IC
IC601 AN22002A-W IC
IC651 MN6627934CH IC
IC671 A42L2604V-45L IC
IC681 SN74AHC1G32DC-X IC
IC682 SN74LV08APW-X IC
IC801 LA6575H-X IC
Q291 2SB1424/QR/-W TRANSISTOR
Q631 2SA1037AK/RS/-X TRANSISTOR
Q851 2SB1424/QR/-W TRANSISTOR
D601 1SS355-X SI DIODE
C201 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C251 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C252 QEKJ0JM-476Z E CAPACITOR 47uF 6.3V M
C253 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C259 NDC31HJ-101X C CAPACITOR 100pF 50V J
C291 QERF0JM-226Z E CAPACITOR 22uF 6.3V M
C603 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C604 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C605 NDC31HJ-391X C CAPACITOR 390pF 50V J
C606 NDC31HJ-560X C CAPACITOR 56pF 50V J
C609 NDC31HJ-470X C CAPACITOR 47pF 50V J
C610 NCB31CK-563X C CAPACITOR 0.056uF 16V K
C611 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C612 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C614 NCB31CK-393X C CAPACITOR 0.039uF 16V K
C615 NCB31HK-272X C CAPACITOR 2700pF 50V K
C616 NCB31HK-182X C CAPACITOR 1800pF 50V K
C621 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C622 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C623 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C624 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C631 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C632 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C633 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C641 NDC31HJ-680X C CAPACITOR 68pF 50V J
C651 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C652 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C653 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C654 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C655 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C656 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C657 NCS31HJ-681X C CAPACITOR 680pF 50V J
C658 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C659 NCB31EK-223X C CAPACITOR 0.022uF 25V K
C661 NCB31HK-102X C CAPACITOR 1000pF 50V K
C662 NCB31CK-823X C CAPACITOR 0.082uF 16V K
C663 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C664 QERF0JM-476Z E CAPACITOR 47uF 6.3V M
C665 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C666 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C667 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C669 NCB31HK-272X C CAPACITOR 2700pF 50V K
C672 NCB31HK-272X C CAPACITOR 2700pF 50V K
C673 QEKJ1CM-106Z E CAPACITOR 10uF 16V M
C674 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C675 NDC31HJ-100X C CAPACITOR 10pF 50V J
C676 NDC31HJ-100X C CAPACITOR 10pF 50V J
C677 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C678 QEKJ0JM-107Z E CAPACITOR 100uF 6.3V M
C681 NCB31CK-103X C CAPACITOR 0.01uF 16V K
C690 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C801 NCB31CK-104X C CAPACITOR 0.1uF 16V K
C802 QERF1AM-227Z E CAPACITOR 220uF 10V M
C803 NCB31AK-474X C CAPACITOR 0.47uF 10V K
C804 NCB31CK-183X C CAPACITOR 0.018uF 16V K
C805 NCB31HK-222X C CAPACITOR 2200pF 50V K
C806 NCB31HK-152X C CAPACITOR 1500pF 50V K
C850 NCB21CK-105X C CAPACITOR 1uF 16V K
C851 QEKJ1CM-107Z E CAPACITOR 100uF 16V M
R253 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
