JVC UX-P400 Service Manual

3-15
CD loading switch board
Block No. [0][4][0][0]
Cassette switch board
Block No. [0][5][0][0]
Head amp. board
Block No. [0][6][0][0]
R255 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R256 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R258 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R259 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R265 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R267 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R271 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R274 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R278 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R285 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R286 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R287 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R288 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R293 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R294 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R295 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R296 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R297 NRSA63J-122X MG RESISTOR 1.2k Ω 1/16W J
R298 NRSA63J-103X MG RESISTOR 10k Ω 1/16W J
R601 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R602 NRSA63J-392X MG RESISTOR 3.9k
Ω 1/16W J
R603 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R604 NRSA63J-274X MG RESISTOR 270k Ω 1/16W J
R605 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R606 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R607 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R608 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R611 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R613 NRSA63J-472X MG RESISTOR 4.7k Ω 1/16W J
R617 NRSA63J-152X MG RESISTOR 1.5k Ω 1/16W J
R631 NRSA63J-470X MG RESISTOR 47 Ω 1/16W J
R632 NRSA63J-3R9X MG RESISTOR 3.9 Ω 1/16W J
R634 NRSA63J-3R9X MG RESISTOR 3.9 Ω 1/16W J
R635 NRSA63J-100X MG RESISTOR 10 Ω 1/16W J
R636 NRSA63J-151X MG RESISTOR 150 Ω 1/16W J
R651 NRSA63J-473X MG RESISTOR 47k Ω 1/16W J
R652 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R653 NRSA63J-223X MG RESISTOR 22k Ω 1/16W J
R654 NRSA63J-753X MG RESISTOR 75k Ω 1/16W J
R655 NRSA63J-105X MG RESISTOR 1M Ω 1/16W J
R656 NRSA63J-104X MG RESISTOR 100k Ω 1/16W J
R657 NRSA63J-821X MG RESISTOR 820 Ω 1/16W J
R658 NRSA63J-241X MG RESISTOR 240 Ω 1/16W J
R659 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R661 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R662 NRSA02J-101X MG RESISTOR 100 Ω 1/10W J
R664 NRSA63J-0R0X MG RESISTOR 0 Ω 1/16W J
R665 NRSA63J-681X MG RESISTOR 680 Ω 1/16W J
R666 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R667 NRSA63J-681X MG RESISTOR 680
Ω 1/16W J
R668 NRSA63J-561X MG RESISTOR 560 Ω 1/16W J
R669 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R671 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
R672 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R673 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R674 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R675 NRSA63J-102X MG RESISTOR 1k Ω 1/16W J
R676 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R678 NRSA63J-270X MG RESISTOR 27 Ω 1/16W J
R679 NRSA63J-0R0X MG RESISTOR 0
Ω 1/16W J
R681 NRSA63J-103X MG RESISTOR 10k
Ω 1/16W J
R682 NRSA63J-391X MG RESISTOR 390 Ω 1/16W J
R801 NRSA63J-472X MG RESISTOR 4.7k
Ω 1/16W J
R802 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R803 NRSA63J-562X MG RESISTOR 5.6k Ω 1/16W J
R805 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R806 NRSA63J-222X MG RESISTOR 2.2k
Ω 1/16W J
R807 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R809 NRSA63J-223X MG RESISTOR 22k
Ω 1/16W J
R811 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R812 NRSA63J-102X MG RESISTOR 1k
Ω 1/16W J
R814 NRSA63J-183X MG RESISTOR 18k
Ω 1/16W J
R815 NRSA63J-153X MG RESISTOR 15k Ω 1/16W J
R816 NRSA63J-562X MG RESISTOR 5.6k
Ω 1/16W J
R821 NRSA63J-473X MG RESISTOR 47k
Ω 1/16W J
R851 NRSA63J-333X MG RESISTOR 33k Ω 1/16W J
R852 NRSA63J-333X MG RESISTOR 33k
Ω 1/16W J
 Symbol No. Part No. Part Name Description Local
CN601 QGF0527F2-15W CONNECTOR FFC/FPC (1-15)
CN602 QGF1036F1-05 CONNECTOR FFC/FPC (1-5)
CN651 QGF1036F1-17 CONNECTOR FFC/FPC (1-17)
K251 NQR0007-002X FERRITE BEADS
K252 NQR0007-002X FERRITE BEADS
K654 NQR0007-002X FERRITE BEADS
SW601 QSW1047-001 PUSH SWITCH
X251 QAX0684-001Z C RESONATOR 8.38MHz
X651 NAX0476-001X CRYSTAL 33.8688MHz
 Symbol No. Part No. Part Name Description Local
CN1 QGF1016F3-05 CONNECTOR FFC/FPC (1-5)
S1 QSW1007-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC1 SG-105F3-BB,C PHOTO SENSER
D1 1SR139-400-T2 SI DIODE
R371 QRE141J-123Y C RESISTOR 12k Ω 1/4W J
VR37 QVP0077-103Z TRIM RESISTOR 10k Ω
CN1 QGF1205F1-09 CONNECTOR FFC/FPC (1-9)
FW100 QUM024-07A2Z3 PARA RIBON WIRE
P1 QNZ0104-001 POST PIN
SW1 QSW0832-001 CASS.SWITCH
SW2 QSW0832-001 CASS.SWITCH
SW5 QSW0832-001 CASS.SWITCH
SW6 QSW0859-001 DETECT SWITCH
 Symbol No. Part No. Part Name Description Local
IC32 HA12238F IC
IC33 CD4094BC IC
Q302 2SC2001/K/-T TRANSISTOR
Q305 2SC2001/K/-T TRANSISTOR
Q342 KRA111M-T DIGI TRANSISTOR
Q343 2SC3576-JVC-T TRANSISTOR
Q344 2SC3576-JVC-T TRANSISTOR
Q345 2SC3576-JVC-T TRANSISTOR
Q346 2SC3576-JVC-T TRANSISTOR
Q347 KRC107M-T DIGI TRANSISTOR
Q371 KTA1271/OY/-T TRANSISTOR
Q372 KRC107M-T DIGI TRANSISTOR
Q375 2SB562/C/-T TRANSISTOR
Q376 KTC3199/GL/-T TRANSISTOR
D340 MTZJ5.1B-T2 Z DIODE
D375 MTZJ5.1B-T2 Z DIODE
C101 QDGB1HK-821Y C CAPACITOR 820pF 50V K
C102 QDYB1CM-103Y C CAPACITOR 0.01uF 16V M
 Symbol No. Part No. Part Name Description Local
