JVC VS-DT9R Service Manual

VS-DT9R/VS-DT6R
3-14
Item
Parts number Parts name Ar
ea
Remarks
A
C 801 NEA70JM-107X E CAPACITOR
C 802 NCB31HK-103X C CAPACITOR
C 803 NEA71HM-475X E CAPACITOR
C 804 NEA71HM-475X E CAPACITOR
C 805 NCB31HK-103X C CAPACITOR
C 806 NCB31HK-103X C CAPACITOR
C 807 NEA70JM-107X E CAPACITOR
C 808 NCB31HK-103X C CAPACITOR
C 809 NDC31HJ-470X C CAPACITOR
C 810 NDC31HJ-101X C CAPACITOR
C 811 NDC31HJ-101X C CAPACITOR
C 812 NCB31HK-103X C CAPACITOR
C 813 NDC31HJ-101X C CAPACITOR
C 814 NDC31HJ-101X C CAPACITOR
CN811 QGF1016F2-17W CONNECTOR FRONT TO MAIN
D 801 EL-19-21SDRC/-X LED
D 802 EL-19-21SDRC/-X LED
D 803 EL-19-21SDRC/-X LED
D 804 EL-19-21SDRC/-X LED
D 805 EL-19-21SDRC/-X LED
D 806 EL-19-21SDRC/-X LED
D 807 EL-19-21SDRC/-X LED
D 808 EL-19-21SDRC/-X LED
D 809 EL-19-21SDRC/-X LED
D 810 EL-19-21SDRC/-X LED
D 811 EL-19-21SDRC/-X LED
D 812 EL-19-21SDRC/-X LED
D 813 EL-19-21SDRC/-X LED
D 814 EL-19-21SDRC/-X LED
D 815 EL-19-21SDRC/-X LED
D 816 EL-19-21SDRC/-X LED
D 817 EL-19-21SDRC/-X LED
D 818 EL-19-21SDRC/-X LED
D 819 EL-19-21SDRC/-X LED
D 820 EL-19-21SDRC/-X LED
DI811 QLF0100-001 FL TUBE
IC811 MN101C35DKB IC(MPU) DISPLAY MICON
IC812 RPM6938-SV4 IC
Q
801 KRC102S-X D.TRANSISTOR
Q
802 KRC102S-X D.TRANSISTOR
Q
803 KRA102S-X D.TRANSISTOR
Q
804 DTC114TKA-X TRANSISTOR
Q
805 KRA102S-X D.TRANSISTOR
Q
806 DTC114TKA-X TRANSISTOR
Q
815 DTA114TKA-X D.TRANSISTOR
Q
816 2SA1037AK/R/-X TRANSISTOR
Q
817 KRC102S-X D.TRANSISTOR
Q
821 DTC114TKA-X TRANSISTOR
R 835 NRSA63J-104X MG RESISTOR
R 861 NRSA63J-561X MG RESISTOR
R 862 NRSA63J-561X MG RESISTOR
R 863 NRSA63J-561X MG RESISTOR
R 864 NRSA63J-561X MG RESISTOR
R 865 NRSA63J-681X MG RESISTOR
R 866 NRSA63J-681X MG RESISTOR
R 867 NRSA63J-0R0X MG RESISTOR
R 868 NRSA63J-0R0X MG RESISTOR
R 869 NRSA63J-681X MG RESISTOR
R 870 NRSA63J-681X MG RESISTOR
R 872 NRSA02J-122X MG RESISTOR
R 873 NRSA63J-681X MG RESISTOR
R 874 NRSA63J-681X MG RESISTOR
R 875 NRSA63J-122X MG RESISTOR
R 876 NRSA63J-122X MG RESISTOR
R 877 NRSA63J-681X MG RESISTOR
R 878 NRSA63J-681X MG RESISTOR
R 879 NRSA63J-122X MG RESISTOR
R 881 NRSA63J-681X MG RESISTOR
R 882 NRSA63J-681X MG RESISTOR
R 885 NRSA63J-681X MG RESISTOR
R 886 NRSA63J-681X MG RESISTOR
R 890 NRSA63J-682X MG RESISTOR
R 891 NRSA63J-102X MG RESISTOR
R 892 NRSA63J-102X MG RESISTOR
R 893 NRSA63J-102X MG RESISTOR
R 894 NRSA63J-102X MG RESISTOR
R 895 NRSA63J-102X MG RESISTOR
R 896 NRSA63J-102X MG RESISTOR
R 897 NRSA63J-102X MG RESISTOR
X 811 NAX0248-001X C OSCILLATOR 8MHZ
Electrical parts list (Front board)
Block No. 02
Item
Parts number Parts name Ar
ea
Remarks
A

JVC VS-DT9R Specifications

General

Brand	JVC
Model	VS-DT9R
Category	Stereo System
Language	English
