JVC VS-DT9R Service Manual

3-15
VS-DT9R/VS-DT6R
Item
Parts number Parts name Ar
ea
Remarks
A
C 254 QERF1AM-476Z E CAPACITOR 47MF 20% 10V
C 255 NCB31CK-104X C CAPACITOR
C 271 NCS31HJ-101X C CAPACITOR
C 272 NCS31HJ-101X C CAPACITOR
C 273 NCB31CK-104X C CAPACITOR
C 291 NCB21CK-105X C CAPACITOR
C 292 NCB21CK-105X C CAPACITOR
C 603 NCB31EK-223X C CAPACITOR
C 604 NCB31EK-223X C CAPACITOR
C 605 NCS31HJ-271X C CAPACITOR
C 606 NCS31HJ-820X C CAPACITOR
C 610 NCB31CK-563X C CAPACITOR
C 611 NCB31CK-104X C CAPACITOR
C 612 NCB31CK-104X C CAPACITOR
C 614 NCB31CK-393X C CAPACITOR
C 615 NCB31HK-272X C CAPACITOR
C 616 NCB31HK-182X C CAPACITOR
C 617 NCB31HK-331X C CAPACITOR
C 621 NCB31CK-104X C CAPACITOR
C 622 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 623 NCB31CK-104X C CAPACITOR
C 624 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 631 QERF1CM-106Z E CAPACITOR 10MF 20% 16V
C 632 NCB31CK-104X C CAPACITOR
C 633 NCB31EK-223X C CAPACITOR
C 651 NCS31HJ-1R0X C CAPACITOR
C 652 NCS31HJ-1R0X C CAPACITOR
C 653 NCB31CK-104X C CAPACITOR
C 655 NCB31CK-104X C CAPACITOR
C 656 NCB31CK-104X C CAPACITOR
C 657 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 658 NCB31CK-104X C CAPACITOR
C 661 NCS31HJ-471X C CAPACITOR
C 663 NCB31EK-223X C CAPACITOR
C 664 NCB31EK-223X C CAPACITOR
C 665 NCB21CK-154X C CAPACITOR
C 667 NCB21CK-474X C CAPACITOR
C 668 NCB31CK-473X C CAPACITOR
C 673 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 676 NCB31CK-104X C CAPACITOR
C 677 NCB31CK-104X C CAPACITOR
C 678 NCB31CK-104X C CAPACITOR
C 679 QERF0JM-107Z E CAPACITOR 100MF 20% 6.3V
C 680 NCB31CK-104X C CAPACITOR
C 681 NCS31HJ-680X C CAPACITOR
C 801 NCB31EK-223X C CAPACITOR
C 802 NCS31HJ-102X C CAPACITOR
C 815 NCB21AK-105X C CAPACITOR
C 816 NCB20JK-155X C CAPACITOR
C 821 NCB31CK-104X C CAPACITOR
C 822 QERF1AM-227Z E CAPACITOR 220MF 20% 10V
C 861 NCB31HK-102X C CAPACITOR
C 862 NCB31HK-102X C CAPACITOR
C 863 NCB31HK-272X C CAPACITOR
C 864 NCB31HK-272X C CAPACITOR
CN601 QGF1036F1-15 CONNECTOR PICK UP/TR.MECH
CN611 QGF1036F1-06 CONNECTOR MOTOR & REST SW
CN612 QGF1036F1-07 FFC/FPC CONNE LOADING MOTOR
CN651 QGB2027L4-18X CONNECTOR MAIN
D 292 MA112-X DIODE
D 603 1SS355-X DIODE
IC251 UPD780024AGKB62 IC
IC291 XC62HR3502P-X IC 3.5VREG
IC601 AN22000A-W IC RF AMP
IC651 MN662790RSC IC
IC801 LA6575H-X IC
K 655 NQR0007-002X FERRITE BEADS
Q
631 2SA1037AK/RS/-X TRANSISTOR APC
R 251 NRSA63J-102X MG RESISTOR
R 252 NRSA63J-102X MG RESISTOR
R 253 NRSA63J-102X MG RESISTOR
R 254 NRSA63J-102X MG RESISTOR
R 255 NRSA63J-102X MG RESISTOR
R 256 NRSA63J-102X MG RESISTOR
R 257 NRSA63J-102X MG RESISTOR
R 258 NRSA63J-102X MG RESISTOR
R 259 NRSA63J-102X MG RESISTOR
R 260 NRSA63J-102X MG RESISTOR
R 261 NRSA63J-0R0X MG RESISTOR
R 262 NRSA63J-102X MG RESISTOR
R 263 NRSA63J-102X MG RESISTOR
R 264 NRSA63J-102X MG RESISTOR
R 265 NRSA63J-102X MG RESISTOR
R 268 NRSA63J-102X MG RESISTOR
R 269 NRSA63J-102X MG RESISTOR
R 270 NRSA63J-222X MG RESISTOR
R 272 NRSA63J-103X MG RESISTOR
R 273 NRSA63J-103X MG RESISTOR
R 274 NRSA63J-682X MG RESISTOR
R 275 NRSA63J-103X MG RESISTOR
R 285 NRSA63J-102X MG RESISTOR
R 286 NRSA63J-102X MG RESISTOR
R 287 NRSA63J-102X MG RESISTOR
R 288 NRSA63J-102X MG RESISTOR
R 291 NRSA63J-103X MG RESISTOR
R 292 NRSA63J-1R0X MG RESISTOR
R 293 NRSA63J-1R0X MG RESISTOR
R 601 NRSA63J-224X MG RESISTOR
R 602 NRSA63J-823X MG RESISTOR
R 603 NRSA63J-393X MG RESISTOR
R 604 NRSA63J-224X MG RESISTOR
R 605 NRSA63J-0R0X MG RESISTOR
R 607 NRSA63J-473X MG RESISTOR
R 608 NRSA63J-473X MG RESISTOR
R 611 NRSA63J-562X MG RESISTOR
R 613 NRSA63J-562X MG RESISTOR
R 617 NRSA63J-152X MG RESISTOR
R 631 NRSA63J-2R2X MG RESISTOR
R 632 NRSA63J-3R9X MG RESISTOR
R 634 NRSA63J-3R9X MG RESISTOR
R 635 NRSA63J-100X MG RESISTOR
R 636 NRSA63J-151X MG RESISTOR
R 651 NRSA63J-102X MG RESISTOR
R 652 NRSA63J-102X MG RESISTOR
R 653 NRSA63J-102X MG RESISTOR
R 654 NRSA63J-102X MG RESISTOR
R 655 NRSA63J-0R0X MG RESISTOR
R 659 NRSA63J-203X MG RESISTOR
R 661 NRSA63J-473X MG RESISTOR
R 662 NRSA63J-683X MG RESISTOR
R 663 NRSA63J-683X MG RESISTOR
R 664 NRSA63J-331X MG RESISTOR
R 665 NRSA63J-101X MG RESISTOR
R 666 NRSA02J-101X MG RESISTOR
R 667 NRSA63J-4R7X MG RESISTOR
R 668 NRSA63J-155X MG RESISTOR
Electrical parts list (CD servo board)
Block No. 03
Item
Parts number Parts name Ar
ea
Remarks
A
