JVC VS-DT9R Service Manual

VS-DT9R/VS-DT6R
3-16
Item
Parts number Parts name Ar
ea
Remarks
A
R 669 NRSA63J-562X MG RESISTOR
R 671 NRSA63J-684X MG RESISTOR
R 675 NRSA63J-100X MG RESISTOR
R 681 NRSA63J-0R0X MG RESISTOR
R 682 NRSA63J-102X MG RESISTOR
R 683 NRSA63J-105X MG RESISTOR
R 685 NRSA63J-683X MG RESISTOR
R 801 NRSA63J-272X MG RESISTOR
R 802 NRSA63J-152X MG RESISTOR
R 803 NRSA63J-472X MG RESISTOR
R 804 NRSA63J-103X MG RESISTOR
R 805 NRSA63J-153X MG RESISTOR
R 808 NRSA63J-273X MG RESISTOR
R 809 NRSA63J-222X MG RESISTOR
R 811 NRSA63J-473X MG RESISTOR
R 812 NRSA63J-152X MG RESISTOR
R 813 NRSA63J-182X MG RESISTOR
R 861 NRSA63J-681X MG RESISTOR
R 862 NRSA63J-681X MG RESISTOR
R 863 NRSA63J-561X MG RESISTOR
R 864 NRSA63J-561X MG RESISTOR
X 251 QAX0664-001Z C OSCILLATOR
X 651 QAX0599-001Z CRYSTAL
Electrical parts list (CD servo board)
Block No. 03
Item
Parts number Parts name Ar
ea
Electrical parts list (CD switch board)
Remarks
Block No. 04
A
CN101 QGA1501F2-04W CONNECTER
CN102 QGF1016F2-07W CONNECTOR
CN103 QGA1501F2-02W CONNECTOR
CN104 QGA1501F2-04W CONNECTER
D 101 GL100MN0MP1/M/X PHOTO DIODE
Q
101 PT100MF0MP1-X PHOTO TR
R 101 NRSA63J-181X MG RESISTOR
S 101 NSW0174-001X PUSH SWITCH
S 102 NSW0174-001X PUSH SWITCH
Item
Parts number Parts name Ar
ea
Electrical parts list (Tra-mecha board )
Remarks
Block No. 05
A
CN105 QGF1016F3-06 CONNECTOR
S 103 QSW0859-001 LEVER SWITCH
