JVC XL-V130BK - Names of Buttons; Main Unit

Page 2
STANDBY
XL-V230 COMPACT DISC PLAYER
STANDBY/ON
PROGRAM
RANDOM REPEAT CANCEL
OPEN / CLOSE
STOP/CLEAR
PLAY / PAUSE
/
/
1 2 3 4 5
6 7 8 9 10 +10
Pulse Edge Modulation Differential Linearity Errorless D/A Converter
P E M D D CONVERTER CONVERTER
COMPULINK-3
(SYNCHRO)
OUTPUT
LEFT
RIGHT
AC POWER CORD
Names of buttons
INTRODUCTION
Numeric keypad
remote sensor
(XL-V230BK Only)
AC power cord inlet
: (STANDBY ON) button
STANDBY
indicator
Display window
Disc tray
COMPU LINK-3 (SYNCHRO) jacks
OUTPUT jacks
4¢ AUTO SEARCH/CHECK buttons
22 33 SEARCH buttons
3/8 PLAY/PAUSE
button
7 STOP/CLEAR
button
PROGRAM button
RANDOM button
random play back button
REPEAT button
CANCEL button
Main unit
0 OPEN/CLOSE button
