JVC XV-M565BK Service Manual

XV-M565BK/M567GD
3-4
Item Parts number Parts name Area
A
Parts list ( General Assembly )
Q'ty Description
Block No. M1MM
1 LV10244-018A FRONT PANEL 1 XV-M567GD
LV10244-015A FRONT PANEL 1 XV-M565BK
2 VJD5429-001SS JVC MARK 1
3 LV10245-006A CONTROL PANEL 1 XV-M567GD
LV10245-001A CONTROL PANEL 1 XV-M565BK
4 LV31260-003A ZOOM BUTTON 1 XV-M567GD
LV31260-001A ZOOM BUTTON 1 XV-M565BK
5 LV20815-002A PLAY BUTTON 1 XV-M567GD
LV20815-001A PLAY BUTTON 1 XV-M565BK
6 LV30787-001A PUSH BUTTON 1 THEATER
7 LV30788-001A PUSH BUTTON 1 DIMMER
8 LV20817-003A LENS
(
VIOLET
)
1 XV-M567GD
LV20817-001A LENS
(
VIOLET
)
1 XV-M565BK
9 QYSDSF2608Z SCREW 6
10 LV32063-001A POWER BUTTON 1 XV-M565BK
LV32063-003A POWER BUTTON 1 XV-M567GD
11 FSJD4001-002 INDICATOR 1
12 QYSDSF2608Z SCREW 8
13 QUQ412-0920CM FFC WIRE 1 CN801 TO CN703
14 LV31375-001A FRONT BRACKET 1
15 QYSDSF2608Z SCREW 4
16 LV31163-005A SHUTTLE RING 1 XV-M567GD
LV31163-004A SHUTTLE RING 1 XV-M565BK
17 QYSDSF2608Z SCREW 3
18 QYSDSG3008N SCREW
(
F.P-CHAS
)
3 XV-M567GD
QYSDSG3008M SCREW
(
F.P-CHAS
)
3 XV-M565BK
19 E103006-007SM CD CHASSIS BASE 1
20 LV31373-001A MECHA.BKT
(
F
)
1 FRONT
21 LV31374-001A MECHA BKT
(
R
)
2 REAR
22 QYSBST3008Z T.SCREW 4 MECHA BKT
23 QZF6018-001 FOOT 2
24 E47227-036 FOOT 2 REAR
25 QYSBST3008Z T.SCREW 4 FOOT
26 LV31244-002A SPACER 2
27 QYSDSG3008M SCREW 2
28 E310244-002 FASTENER 1 AUDIO CB
29 QYSBSGG3008E T.SCREW 1 AUDIO CB
30 QUQ412-1020CM FFC WIRE 1 CN702 TO C5
31 QUQ110-2318AM FFC WIRE 1 CN701 TO C5
32 QYSBSGG3008E T.SCREW 2
33 E310244-002 FASTENER 1
34 QMF51U1-1R6-J8 FUSE
A
1 F901
35 LV41362-001A HEAT SINK 1
36 LV41363-002A HOLDER 1
37 E310244-003 FASTNER 1
43 QYSBSF3008Z SCREW 1 MODULE CB
44 QUQ110-1910AJ FFC WIRE 1 PU-MODULE FW101
45 QUQ110-1110AJ FFC WIRE 1 PU-MODULE FW102
