JVC XV-M565BK Service Manual

XV-M565BK/M567GD
3-5
Item Parts number Parts name Area
A
Q'ty Description
Block No. M1MM
46 QJJ015-091204 SIN CR C-C WIRE 1 TO CN961
47 QUQ110-0923AM CARD WIRE 1 TO CN601
48 E309662-001SM DISC STOPPER 1
49 QYSBSF3008Z SCREW 1
50 QYSBST3008Z T.SCREW 4 MECHA
51 LV10282-001A SHIELD CASE 1
52 QYSBSGG3008E T.SCREW 4 SHIELD CASE
53 LV20821-014A REAR PANEL 1 XV-M565BK
LV20821-020A REAR PANEL 1 XV-M567GD
54 QYSBSGY3008E SPECIAL SCREW 3 REAR PANEL
55 QYSBSGY3008E SPECIAL SCREW 1 VIDEO OUT
56 QYSBSGY3008E SPECIAL SCREW 2 AV OUT
57 QYSBSGY3008E SPECIAL SCREW 1 COMPU.LINK
58 QYSBSGY3008E SPECIAL SCREW 1 COAXIAL OUT
59 QYSBSGY3008E SPECIAL SCREW 1 AUDIO OUT
60 QYSBSGY3008E SPECIAL SCREW 1 OPTICAL OUT
61 QYSBSGY3008E SPECIAL SCREW 1 AC OUTLET
62 LV20818-001A FITTING
(
DISC1 LOWER
)
1 XV-M565BK
LV20818-003A FITTING
(
DISC1 LOWER
)
1 XV-M567GD
63 LV20819-002A FITTING
(
DISC2 CENTR
)
1 XV-M567GD
LV20819-001A FITTING
(
DISC2 CENTR
)
1 XV-M565BK
64 LV20820-001A FITTING
(
DISC3 UPPER
)
1 XV-M565BK
LV20820-002A FITTING
(
DISC3 UPPER
)
1 XV-M567GD
65 LE40564-002A MARK 1
66 LE30714-001A KNOB
(
SHUTTLE
)
1 XV-M565BK
LE30714-005A KNOB
(
SHUTTLE
)
1 XV-M567GD
67 LV20009-310A METAL COVER 1 XV-M567GD
LV20009-311A METAL COVER 1 XV-M565BK
68 E406308-003 S.SCREW
(
SIDE M.COVER
)
4 XV-M565BK
E406308-004 S.SCREW
(
SIDE M.COVER
)
4 XV-M567GD
69 QYSBSGY3008E SPECIAL SCREW 2 M.COVER REAR
72 -------------------- DVD 3CHANGER LO 1 BDL1081-M001YP
73 E306805-134 SPACER 1
74 LE40505-001A HEAT SINK 1 HS964
75 QLF0064-001 FL TUBE 1 DI801
LV30225-059A SPACER 3
76 E308192-001 FL HOLDER 1 BK801
Parts list ( General Assembly )
