JVC XV-S42SL Service Manual

XV-S40BK/XV-S42SL/XV-S45GD
XV-S30BK/XV-E100SL
1-39
8765
1234
B
A
V+ B OUT B -IN B +IN
V-A +INA -INA OUT
NJM4580M-X (IC741,IC751) : Dual OP amplifier
Block diagram
1 2 3
INPUT
OUTPUT
GND
NJM78M05FA (IC953) : Regulator
1.INPUT
2.GND
3.OUTPUT
1.Terminal layout 2.Block diagram
2.Block diagram1.Terminal layout
PQ05RD21 (IC951) : Regulator
PQ05RD21
Vin
Vout
GND
Vcontrol
2
1
3
4
Vcontrol
Voutput
Vinput
GND
