3-3
XV-S40BK/XV-S42SL/XV-S45GD
XV-S30BK/XV-E100SL
Item
Parts number Parts name
Area
A
A
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
1 LE10251-246A FRONT PANEL 1,21
LE10251-244A FRONT PANEL 5,7,8,9,101
LE10251-245A FRONT PANEL 111
LE10251-247A FRONT PANEL 12,131
LE10251-248A FRONT PANEL 14,15,161
LE10251-241A FRONT PANEL 3,41
LE10251-243A FRONT PANEL 61
2 GN40006-001A JVC MARK 1 1,2,3,4,11
GN40006-002A JVC MARK 5-10,12-161
3 E75896-001 FELT SPACER 1-112
LE40798-001A SPACER 12,13,14,15,162
4 LE30898-001A WINDOW SCREEN 1,21
LE20535-006A WINDOW SCREEN 5,7,8,9,101
LE20535-005A WINDOW SCREEN 3,4,6,111
LE20535-011A WINDOW SCREEN 12,131
LE20535-002A WINDOW SCREEN 14,15,161
5 LE30900-001A INDICATOR 1
6 LE20537-001A PUSH BUTTON 1,2,3,41
LE20537-002A PUSH BUTTON 5-10,12-161
LE20537-003A PUSH BUTTON 111
7 QYSBSF2608Z T.SCREW 2
8 LE30899-001A REMOTE LENS 1,2,3,41
LE30899-002A REMOTE LENS 1 5-16
9 QYSBSF2608Z T.SCREW 1
10 LE20538-001A PUSH BUTTON 1,2,3,41
LE20538-002A PUSH BUTTON 5-10,12-161
LE20538-003A PUSH BUTTON 111
11 QYSBSF2608Z T.SCREW 3
12 QYSDSG3008M SCREW 1,2,3,41
QYSDSG3008N T.SCREW 1 5-16
13 LE10250-002A CHASSIS BASE 1
14 E75896-001 FELT SPACER 1-112
LE40798-001A SPACER 12,13,14,15,162
15 LE40768-002A PROTECT SHEET 1-4,6,11-131
LE40768-003A PROTECT SHEET 5,7-10,14-161
16 QYSBSGG3008E T.SCREW 4
17 --------- TRAVERSE MECHANISM 1
18 LV41659-201A INSULATOR 4
19 LV41424-001A SPECIAL SCREW 4
20 --------- LOADING MECHANISM
See 3-5 page
See 3-7 page1
21 QMF51U1-1R6-J8 FUSE 1-4,6,11-131
QMF51E2-1R6-J1 FUSE 5,7-10,14-161
22 LE20541-001A/S/ METAL COVER 1,2,3,41
LE20541-002A/S/ METAL COVER 5-10,12-161
LE20541-003A/S/ METAL COVER 111
23 QYSBSGG3008E T.SCREW 3
Explanation of area column
1 =XV-S30BK ver. C
2 =XV-S30BK ver. J
3 =XV-S40BK ver. C
4 =XV-S40BK ver. J
9 =XV-S42SL ver. US
10 =XV-S42SL ver. UW
11 =XV-S45GD ver. J
12 =XV-E100SL ver. J
13 =XV-E100SL ver. C
14 =XV-E100SL ver. UB
15 =XV-E100SL ver. UP
16 =XV-E100SL ver. US
5 =XV-S42SL ver. A
6 =XV-S42SL ver. C
7 =XV-S42SL ver. UG
8 =XV-S42SL ver. UP
