JVC XV-S42SL Service Manual

3-4
XV-S40BK/XV-S42SL/XV-S45GD
XV-S30BK/XV-E100SL
Item
Parts number Parts name Area
A
Parts list (General assembly)
Q'ty
Description
Block No. M1MM
E406308-004 SPECIAL SCREW 2
25 LE20536-001A FITTING 1,2,3,41
LE20536-002A FITTING 5,6,7,8,9,101
LE20536-003A FITTING 111
LE20536-005A FITTING 12,13,14,15,161
26 LE40757-002A MARK 12,13,14,15,161
27 LV10455-002A TRAY 1
28 LV20913-002A CLAMPER BASE 1
29 LV32417-001A CLAMPER 1
30 LV42089-001A YOKE 1
31 LV41118-003A MAGNET 1
32 LV41741-001A SPECIAL SCREW 1
33 QYSBSF2008Z SCREW 4
34 QYSBSGY3008M SPECIAL SCREW 1
35 QYSBSGY3008M SPECIAL SCREW 1
37 QYSBSGY3008M SPECIAL SCREW 2
38 QYSBSGY3008M SPECIAL SCREW 1
5-16
3-16
3-16
39 QYSBSGY3008M SPECIAL SCREW
AC INLET
COMPU LINK
VIDEO OUT
OPTICAL OUT
REAR + CHASSIS1
40 LE20542-029A REAR PANEL 1,21
LE20542-026A REAR PANEL 101
LE20542-028A REAR PANEL 111
LE20542-049A REAR PANEL 12,131
LE20542-050A REAR PANEL 14,161
LE20542-052A REAR PANEL 151
LE20542-023A REAR PANEL 3,41
LE20542-014A REAR PANEL 51
LE20542-025A REAR PANEL 61
LE20542-008A REAR PANEL 71
LE20542-022A REAR PANEL 81
LE20542-010A REAR PANEL 91
41 QYSBSG3010E T.SCREW 3
42 LE20540-001A FL HOLDER 1
43 LE40759-001A FL SCREEN 12,13,14,15,161
45 LE30001-031A SPACER 1-4,6,11-132
24 E406308-003 SPECIAL SCREW 1,2,3,42
Explanation of area column
1 =XV-S30BK ver. C
2 =XV-S30BK ver. J
3 =XV-S40BK ver. C
4 =XV-S40BK ver. J
9 =XV-S42SL ver. US
10 =XV-S42SL ver. UW
11 =XV-S45GD ver. J
12 =XV-E100SL ver. J
13 =XV-E100SL ver. C
14 =XV-E100SL ver. UB
15 =XV-E100SL ver. UP
16 =XV-E100SL ver. US
5 =XV-S42SL ver. A
6 =XV-S42SL ver. C
7 =XV-S42SL ver. UG
8 =XV-S42SL ver. UP
