JW Fishers SFP-1 User Manual

7 8
12345
1
234
5
12345
12
12
12
12
12
12
5
2
.5
.1
Power Output
(2 Watt selected)
Battery
#1
123456
1
2345
6
123456
12
12
12
12
2
.5
1
123456
1
2345
6
123456
12
12
12
12
2
4
3
Pulse Length
(4 ms selected)
1234
1
23
4
1
23
4
1
23
4
1234
12
12
12
12
12
Water
Power Activation
(water activation selected)
On Off
123456789012
1
2345678901
2
1
2345678901
2
123456789012
12345
1
234
5
12345
12
12
12
12
12
12
= jumper installed
Metal Contacts
(for Water power activation)
Multifrequency Pinger Jumper Layout
Note:
The frequency selection
switch is mounted on the
back side of this board
Desired Freq Switch
Frequency Settings
20000 ................. 11100100
20500 ................. 00010100
21000 ................. 10010100
21500 ................. 01010100
22000 ................. 11010100
22500 ................. 00110100
23000 ................. 10110100
23500 ................. 01110100
24000 ................. 11110100
24500 ................. 00001100
25000 ................. 10001100
25500 ................. 01001100
26000 ................. 11001100
26500 ................. 00101100
27000 ................. 10101100
27500 ................. 01101100
28000 ................. 11101100
28500 ................. 00011100
29000 ................. 10011100
29500 ................. 01011100
30000 ................. 11011100
30500 ................. 00111100
31000 ................. 10111100
31500 ................. 01111100
32000 ................. 11111100
32500 ................. 00000010
33000 ................. 10000010
33500 ................. 01000010
34000 ................. 11000010
34500 ................. 00100010
35000 ................. 10100010
35500 ................. 01100010
36000 ................. 11100010
36500 ................. 00010010
37000 ................. 10010010
37500 ................. 01010010
38000 ................. 11010010
38500 ................. 00110010
39000 ................. 10110010
39500 ................. 01110010
40000 ................. 11110010
40500 ................. 00001010
41000 ................. 10001010
41500 ................. 01001010
42000 ................. 11001010
42500 ................. 00101010
43000 ................. 10101010
43500 ................. 01101010
44000 ................. 11101010
44500 ................. 00011010
45000 ................. 10011010
45500 ................. 01011010
46000 ................. 11011010
46500 ................. 00111010
47000 ................. 10111010
47500 ................. 01111010
48000 ................. 11111010
48500 ................. 00000110
49000 ................. 10000110
49500 ................. 01000110
50000 ................. 11000110
Frequency
Selection Switch
Switch
is on
Switch
is off
Frequency
Switch
Multifrequency Pinger
(Sample setting
is for 20,000Hz)
(Front side of board shown)
(Back side of board shown)
Transducer
Transducer
Multifrequency Pinger
(Frequency Selection Switch)
Retaining Cap
ON
Rep Rate (seconds between pulses)
(1 sec rep rate selected)
