14. KA-PoT1 ACCESSoRY
KA-POT1 allows users to control input channels and output channels levels with a potentiometer installed
in a standard box for switches. It is possible to connect up to two independent KA-POT1 to each amplifier
in order to control two independent levels.
To assign each KA-POT1 an amplifier parameter, connect a computer running the K-framemork software
and follow the instruction you find in the K-framework manual. As shown in the window below, users can
assign each KA-POT1 one or more channel levels. In the example below, the first KA-POT1 controls all
input channel volumes and the second controls all output channel volumes.
14.1 ChANNEL LEvELS ASSIGNMENT
