8. INSTALLATIoN
KA24 and KA84 are two rack units high (2U) and can be mounted in an EIA-standard 19’’ rack using
two rack adapters (included). In case of istallation on a flat surface, use the four rubber pads included.
To maintain a low and even operating temperature, the amplifier contains two fans on the right side.
The figure below shows the air flow:
WARNING
For effective cooling, do not obstruct the ventilation openings.
