EF680/EF780 Installation Guide
Fitting the Main Body of the Lock
Step 8
Double Locking Model Only.
If tting a single locking model please go to Step 9.
Prior to placing the main body to the backing plate make
sure that the clutch is pushed down and not out as shown
in picture A.
Picture B is the correct placement of the clutch.
A. B.
