Kaba SIMPLEX 900 Series Installation Instructions

1514
Notes
TOP FOR RIGHT HAND DOORS
Attach to inside surface of shut door
Door handing should be determined before door
prep is started to avoid incorrect door preparation.
Door handing should be determined before door
prep is started to avoid incorrect door preparation.
Attach to inside surface of shut door
TOP FOR LEFT HAND DOORS
Fold along dash line for outswing door or if you are using a riser plate on an inswing door
Fold along solid line for inswing door (no riser plate) See step 2 in instructions
SERIES 900 TEMPLATE
PKG2348E 0307
1
/
8
"
dia.
(3 mm)
1
/
8
"
dia.
(3 mm)
1
/
8
"
dia.
(3 mm)
7
/
8
"
dia.
(22 mm)
1
5
/
8
"
dia.
(41 mm)
*7
/
8
"
dia.
(22 mm)
* Drill only if lock
model has key
override function
