Kaba SIMPLEX 900 Series User Manual

39
SIMPLEX
®
Installation
Backset: 2
9
⁄16" (65 mm) for outswing doors, 2
1
⁄2" (64 mm) for inswing doors
Door Thickness: 1
3
⁄8" (35 mm) to 1
1
⁄2" (38 mm)
1
3
⁄4" (44 mm) to 2
1
⁄8" (54 mm)
Model 929: Lockset for DOD standards, 1
3
⁄4" (44 mm) to 2
1
⁄8" (54 mm) only
Items Supplied Include: Installation manual, full-scale template, strike for inswing and outswing doors
(appropriate to latch type), and required installation hardware
Certification and Testing
Durability: Highly weather resistant
Warranty
Warranty: 1-year warranty
Auxiliary Lock
3
3
⁄4"
(95 mm)
2
9
⁄16"
(65 mm)
1
9
⁄16"
(40 mm)
5
⁄8"
(16
mm)
Key Override
5
"
(127
mm)
3
11
⁄16"
(94
mm)
1
1
⁄8"
(29 mm)
2
1
⁄16"
(52
mm)
Exterior
Exterior Side
Interior Side
Interior
(Spring latch models)
• Combination Entry
• Deadbolt
• 1" (25 mm) Throw,
Flat Face Plate
• Auxiliary Lock
• Manual Relock
• Key Override (Select
Models)
Models 902, 904, 906, 910
Models 929
Models 917, 919, 935, 938
• Combination Entry
• Deadlocking Latch
•
5
⁄8" (16 mm) Throw,
Flat Face Plate
• Primary or Auxiliary Lock
• Automatic Relock
• Key Override (Select
Models)
• Combination Entry
• Security Lock
•
5
⁄8" (16 mm) Throw
• Primary or Auxiliary Lock
• Automatic Relock
• DOD Compliant
Simplex
®
900 Series
15
⁄16"
(24 mm)
