Kaba SIMPLEX 900 Series User Manual

40
SIMPLEX
®
Example
20
9
04 1
Build the model number with the desired options
Model Options
9
4 1
Finish
-
---
-
000 6
2
D
Base Model Description
902000026D41 Auxiliary Lock with Thumbturn,
1" (25 mm) Deadbolt, Fits 1
3
⁄8" – 1
1
⁄2"
(35mm – 38mm) thick
Choose one option from this category
Model Options Description
02 1" (25 mm) Deadbolt latch,
1
3
⁄8"–1
1
⁄2" (35 mm–38 mm) thick
04 1" (25 mm) Deadbolt latch,
1
3
⁄4"–2
1
⁄8" (44 mm–54 mm) thick
06 1" (25 mm) Deadbolt latch, 1
3
⁄8"–1
1
⁄2"
(35 mm–38 mm) thick key override
10 1" (25 mm) Deadbolt latch, 1
3
⁄4"–2
1
⁄8"
(44 mm–54 mm) thick key override
17
5
⁄8" (16 mm) Deadlocking spring latch, flat
front, 1
3
⁄8"–1
1
⁄2" (35 mm–38 mm) thick
Latch holdback
19
5
⁄8" (16 mm) Deadlocking spring latch, flat
front, 1
3
⁄4"–2
1
⁄8"(44 mm–54 mm) thick
Latch holdback
20
5
⁄8" (16 mm) Deadlocking spring latch, flat
front, 1
3
⁄8"–1
1
⁄2" (35 mm–38 mm) thick
No latch holdback
22
5
⁄8" (16 mm) Deadlocking spring latch, flat
front, 1
3
⁄4"–2
1
⁄8" (44 mm–54 mm) thick
No latch holdback
29
++
5
⁄8" (16 mm) Deadlocking spring latch, flat
front, 1
3
⁄4"–2
1
⁄8" (44 mm–54 mm) thick
35
5
⁄8" (16 mm) Deadlocking spring latch, flat
front, 1
3
⁄8"–1
1
⁄2" (35 mm–38 mm) thick
Latch holdback, key override
38
5
⁄8" (16 mm) Deadlocking spring latch, flat
front, 1
3
⁄4"–2
1
⁄8" (44 mm–54 mm) thick
Latch holdback, key override
Choose up to 4 options—Insert 0 if less
than 4 options are required.
Options Description
1 Substitutes a surface mounted strike box for
metal door frames
in place of the standard
strike box (part number 74464).
(See 900 Series Accessories— Adapter list)
2 Deletes the key cylinder from key override
models. Recessed escutcheon recommended
for standard rim cylinder installation. Your
rim cylinder tailpiece must be reduced in
width to accommodate the tail receptacle.
Specify the position of your cylinder tailpiece
(vertical or horizontal) to mate with your
standard size rim cylinder (not supplied).
3 Substitutes a 2
1
⁄2" (64 mm) lever in place of
the standard inside thumbturn (part number
74437)
4 Master key (key override models).
5 Adds the panic bar release kit to a spring
latch model (part number 74438)
6 Delete latch holdback
(935 and 938 models).
7 Deletes the key cylinder from key override
models and changes gear plate to a 100
Series. Recessed escutcheon recommended
for standard rim cylinder installation. Your
rim cylinder tailpiece must be reduced in
width to accommodate the tail receptacle.
Specify the position of your cylinder tailpiece
(vertical or horizontal) to mate with your
standard size rim cylinder (not supplied).
8 Changes gear plate to accept a
horizontal tailpiece.
Finish Options Description
26D Satin Chrome (Powder Paint)
04
+
Satin Brass (Powder Paint)
Notes
+
04 Finish not available on Model 929
++
DOD Compliant
