MDM2010 – ILB3210 Installation Guide
10 | Page
2.2.2 Cable Path
Kacific supplies a single coaxial cable for the Tx/Rx connection between the
transceiver and the modem.
This coaxial cable must be protected:
- Inside a covered cable tray (As indicated in (1)) OR
- Within a plastic/metal pipe (As indicated in (2))
2
Note: The length of the cable must not be more than 30 meters.
Kacific does not approve installations with more than 30 meters of L-Band cable.
