Opening the menu
↻ The device is in operation and the LCD is showing the desktop.
F Press the right arrow button.
ð The menu moves over the desktop from left to right.
Displaying the daily output
↻ The device is in operation and the LCD is showing the desktop.
F Press the down arrow button.
ð The LCD displays the daily yield in a diagram.
F To return to the desktop, press any button.
Device menu
Selecting a menu option
↻ You have left the desktop. The device displays the menu.
F Use the up button or down button to navigate.
Opening a menu item or a setting
F Use the right arrow button and the Enter button.
Navigate to the next higher menu level/discard change
F Use the left arrow button or the ESC button.
Selecting an option
F Use the right and left arrow buttons.
Changing an option/the value of an input field
F Use the up and down arrow buttons.
Saving changed setting
F Press the Enter button.
9 | Configuration and operation Manual
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 34
EN
