Kaco blueplanet 3.0 TL3 M2 WM OD IIG0 User Manual

4
1
2
3
4
Const. volt. ctrl
NOTE:Option to disable the MPP seek mode in order to oper-
ate the device with a constant DC voltage.
1. Activate or disable the constant voltage controller.
2. Set value for constant voltage controller.
CAUTION!When constant voltage operation and "Q on De-
mand" operation are activated, feedback can occur on the PV
generator. Please observe the instructions and approval of the
module manufacturer.
4
1 2
3
4
Insul. resistance F Set threshold value (in 1kOhm increments) at which the insulation
monitor reports a fault.
4
1 2
3
4
Grid monitoring 3-
phase
On / Off
NOTE:The device is equipped with redundant 3-phase monit-
oring. If the grid voltage exceeds or drops below the con-
figured values, the device switches off. The minimum switch-
off threshold can be set in 1V increments.
F Activate or disable monitoring.
4
1
2
3
4
FRT (Fault Ride
Through)
NOTE:The device supports dynamic grid stabilization (Fault
Ride-Through).NOTE: More detailed information at: [See sec-
tion10.3}Page64]
4
1 2
3
4
Operation mode –
On | Off
F Select a control process.
On: Activates dynamic grid support using dynamic reactive current.
Off: Deactivates dynamic grid support using dynamic reactive current.
Dynamic grid support remains active on account of immunity to inter-
ference.
Setting | Manual |Pre-
defined zero current
F Select a control process.
Priority – Reactive cur-
rent limitation | Active
current priority
F Select a control process.
4
1 2
3
4
Constant k positive se-
quence dip &
Constant k positive se-
quence swell
k 0 – 10 2
F Set amplification factor k for the pos. sequence for drop and increase
in the grid voltage.
4
1 2
3
4
Constant k negative se-
quence dip
Constant k negative se-
quence swell
k 0 – 10 2
F Set amplification factor k for the neg. sequence for drop and increase
in the grid voltage.
4
1 2
3
4
Dead band
0 - 100 [% Uref]
10.0
F Set dead band in %.
4
1 2
3
4
Dynamic reactive cur-
rent only
Off | On
NOTE:With FRT mode activated, the pre-fault reactive current
can be added.
F If necessary, activate pre-fault reactive current.
4
1 2
3
4
Dead band mode
Mode 1 | Mode 2
F Select dead band mode for the active control process.
4
1 2
3
4
Reference voltage
U< - U>
F Set reference voltage for the active control process.
9 | Configuration and operation Manual
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 46
EN
