Kaco blueplanet 3.0 TL3 M2 WM OD IIG0 User Manual

No. Grid
LED
LED Display Status description Action Pers
.
150 Protective shutdown drop
1.65V
Internal voltage supply incorrect. Internal ref-
erence voltage of 1.65 V on control card has
breached its permitted tolerance range.
- -
151 Input current limitation DC1 No error message, merely a protective func-
tion of the inverter to prevent the current car-
rying capacity of the input from being ex-
ceeded. Input current limitation DC1 The DC
input current 1 is limited once the specified
maximum value has been reached. Safety
function of the inverter.
Are the DC inputs
wired symmetric-
ally?
-
152 Input current limitation DC2 No error message, merely a protective func-
tion of the inverter to prevent the current car-
rying capacity of the input from being ex-
ceeded. Input current limitation DC2 The DC
input current 2 is limited once the specified
maximum value has been reached. Safety
function of the inverter.
Are the DC inputs
wired symmetric-
ally?
-
153 Input current limitation DC3 No error message, merely a protective func-
tion of the inverter to prevent the current car-
rying capacity of the input from being ex-
ceeded. Input current limitation DC3 The DC
input current 3 is limited once the specified
maximum value has been reached. Safety
function of the inverter.
Are the DC inputs
wired symmetric-
ally?
-
154 Input power limitation DC1 No error message, merely a protective func-
tion of the inverter to prevent the capacity of
the input from being exceeded. Input power
limitation DC1 The DC input power is limited
once the specified maximum value has been
reached. Safety function of the inverter.
Are the DC inputs
wired symmetric-
ally?
-
155 Input power limitation DC2 No error message, merely a protective func-
tion of the inverter to prevent the capacity of
the input from being exceeded. Input power
limitation DC2 The DC input power is limited
once the specified maximum value has been
reached. Safety function of the inverter.
Are the DC inputs
wired symmetric-
ally?
-
156 Input power limitation DC3 No error message, merely a protective func-
tion of the inverter to prevent the capacity of
the input from being exceeded. Input power
limitation DC3 The DC input power is limited
once the specified maximum value has been
reached. Safety function of the inverter.
Are the DC inputs
wired symmetric-
ally?
-
157 Control board watchdog Control board watchdog triggered Notify the service
department.
E
160 Error: Grid relay L1 During the self-test, it is discovered that the
grid-side L1 relay becomes stuck. The self-test
does not check whether the relay switches on.
Grid-side L1 relay defective
- -
161 Error: Grid relay L2 - - -
162 Error: Grid relay L3 - - -
11 | Maintenance and troubleshooting Manual
KACO blueplanet 3.0 TL3 KACO blueplanet 4.0 TL3 KACO blueplanet 5.0 TL3 KACO blueplanet 6.5 TL3 KACO
blueplanet 7.5 TL3 KACO blueplanet 8.6 TL3 KACO blueplanet 9.0 TL3 KACO blueplanet 10.0 TL3
Page 84
EN
