SIGMA CONTROL BASIC program module
KAESER KOMPRESSOREN GmbH 03.06.2003 www.kaeser.com
3.3 Checking acceptance of the new program
- Start the controller and allow it to boot up.
- Switch the controller off.
- Switch the controller on again. During booting up the display should show:
SBSxx.xx_R
3.4 Entering the counter readings
Enter the readings as noted (see 3.1):
- parameter 0: operating hours
- parameter 1: hours under load
- parameter 2: hours to next service (interval)
3.5 Electrical connection
The connection of the volt-free contact for load/idle control is directly on the rear of the
controller. Only flexible cable may be used with conductor section 0.5 - 1.5 mm² (AWG 22 -
16) - recommended cable is NYSLYÖ 2 x 1.0mm². Maximum cable length 100m.
plugged in
Voltfree contact for remote
load/idle control
