1.1 Keys and Indicators
Fig. 1 Keys
Symbol
Item Description Function
1 ON (I) Switch the machine on.
2 OFF (0) Switch the machine off.
Acknowledges alarm messages and resets event
memory.
6 Arrow key Scrolls down parameter list.
Reduces a parameter value.
7 Arrow key Scrolls up the parameter list.
Increases a parameter value.
8 Escape Exits the edit mode without saving.
9 Return/enter/save
key
Only affects the message in the third line of the dis-
play (12).
Jumps to the edit mode.
Saves and leaves the edit mode.
Tab. 1 Buttons
