Extract from Service Manual
1 --- 4
1.2.3 Parameter setting
The edit mode can be entered by depressing the ”Enter” key for three seconds.
If a password is needed it is requested automatically.
Every action may be retracted by means of the escape key (esc).
If no key is pressed in the edit mode for ten seconds the display automati-
cally returns to the previous mode.
Restarting the controller is not necessary. Edited parameters are immedi-
ately effective.
System pressure and airend discharge temperature are neither updated
nor displayed whilst in the edit mode.
Scroll with the arrow keys until the desired parameter appears in line 3.
Depress the enter key for at least three seconds.
Without password protection
The current parameter setting blinks.
Use the arrow keys to change the setting and confirm with the enter key.
With password protection
The password consists of five characters. The first character blinks.
Use the arrow keys to change the setting and confirm with the enter key.
The next character blinks.
Repeat setting until all characters are entered.
When the correct password is entered the parameters are displayed.
Use the arrow keys to change the setting and confirm with the enter key.
1.2.4 Alarm and warning message recognition
A complete list with instructions on fault rectification is given in chapter 9.
