Kaisai KHC-12RY3 - Page 114

Filter board(PCB C)(at back of the
PCB B,only for 3 phase unit)
12/14/16kW(3-phase)
Main control board of hydraulic module
Inverter module
control board(PCB A)
Main control board
of heat pump sysem(PCB B)
114
